Air Water Heat Pump,DC Inverter Air Water Heat Pump, Air Source Heat Pump Water Heater Inverter
US$ 1 - 2,000
MOQ: 50 Sets
Key Specifications
Get Latest Price
Type:
Other, solar
Pressure:
Pressurized
Circulation Type:
Direct / Open Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Geothermal Water Source ,to Water Heat Pump, Water Heat PumpUS$ 1 - 2,000MOQ: 50 Sets -
Solar Water Source Heat Pump ,solar Water Heat Pump, Solar Heat PumpUS$ 1 - 2,000MOQ: 50 Sets
-
Air Water Heat Pump ,solar Powered Heat Pumps, Duct Solar Air Source Heat PumpUS$ 1 - 2,000MOQ: 50 Sets
-
Air Source Heat Pump for Low Temperature,ductless Heat Pump,ground Source Heat Pump to WaterUS$ 1 - 2,000MOQ: 50 Sets
-
Commercial Water Source ,heating Pump,low Ambient Temperature Heat PumpUS$ 1 - 2,000MOQ: 50 Sets
Type
Other, solar
Pressure
Pressurized
Circulation Type
Direct / Open Loop (Active)
Heating System
Thermosyphon (Passive)
Connection Type
Split
Installation
Wall Mounted
Housing Material
Stainless Steel
Certification
CB, CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR
Capacity
18000
Place of Origin
Shanghai, China
Brand Name
YUAO
Model Number
YACH-5000W
air water heat pump,DC inverter air water heat pump, air source heat pump water heater inverter
inverter heat pump,DCinverter heat pum water heater,DCinverter heat pump water heater
solar heat pump, solar air-conditioner,air heat pump water heater,water pump solar,air-conditioner,Hybrid Solar airconditioner,cooling unit,mix solar air cooling & heat pump,solar air conditioner
| Technical Data | 18K | 24K | 36K | |||||||
| Cooling Capacity | W | 3,100 | 5,200 | 6,300 | 3,500 | 7,000 | 8,000 | 5,000 | 9,600 | 10,500 |
| Heating Capacity | W | 3,200 | 5,800 | 6,800 | 3,600 | 7,500 | 8,400 | 5,200 | 10,200 | 11,200 |
| Power Input (Cooling) | W | 1,600 | 2,320 | 3,150 | ||||||
| Power Input (Heating) | W | 1,680 | 2,200 | 2,950 | ||||||
| Voltage | 230/1/50 | 230/1/50 | 230/1/50 | |||||||
| EER | W/W | 3.25 | 3.02 | 3.05 | ||||||
| Energy Class (Cooling) | A | B | B | |||||||
| COP | W/W | 3.45 | 3.41 | 3.46 | ||||||
| Energy Class (Heating) | A | B | B | |||||||
| Indoor Unit | ||||||||||
| Static Pressure | Pa | 40 | 50 | 60 | ||||||
| Airflow | m3/h | 810/750/680/630 | 1100/1020/930/840 | 1690/1580/1450/1330 | ||||||
| Sound Level | dB(A) | 39/37/35/33 | 40/38/36/34 | 43/41/39/36 | ||||||
| Dimensions | (WxHxD)mm | 780x240x560 | 780x240x560 | 932x285x662 | ||||||
| Net Weight | Kgs | 31 | 34 | 41 | ||||||
| Outdoor Unit | ||||||||||
| Dimensions | (WxHxD)mm | 850x580x290 | 840x680x310 | 875x850x310 | ||||||
| Sound Level | dB(A) | 51 | 52 | 56 | ||||||
| Compressor Type | Rotativo/Rotary | |||||||||
| Net Weight | Kgs | 43 | 55 | 70 | ||||||
| ø Liquid Pipe | Inch | 1/4 | 3/8 | 3/8 | ||||||
| ø Gas Pipe | Inch | 1/2 | 5/8 | 5/8 | ||||||
| Max. Piping Lenght | m | 25 | 50 | 50 | ||||||
| Max. Height Diff. | m | 15 | 30 | 30 | ||||||
| 1.Refrigerant charge is valid for 7m (model 18K), and 10m for the rest. | ||||||||||
| 2.Capacity and electrical data are given under the following conditions: | ||||||||||
| 3.Cooling: 27ºC(db) y 19ºC(wb) indoor and 35ºC(db) outdoor. | ||||||||||
| 4.Heating: 20º(db) indoor and 7ºC(db) y 6ºC(wb) | ||||||||||
....
