Home > Products > cabinet(industrial) air conditioner > cooling server network cabinet
cooling server network cabinet
- 10000 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | YUAO | Model Number: | OC03-OC40 |
Product Description
cooling server network cabinet
Features :
- Refrigerant: R134a
- Digital control mode, can reach high accuracy.
- The unit can work perfectly from -40 to +55 Degrees Celsius.
- Keep the dust, oil fog and moisture from entering the internal of the equipments. IP23
- The structure design makes the installation more flexible. And the unit can be installed perfectly in the side or outside wall of the equipment
- The protective level of internal and external circulation is IP55, which can protect cabinet to avoid moisture, dust, water and also it can be installed inside and outside.
- Digital temperature controlled and high precision of temperature control.
- Unique condensate treatment system, no condensate discharge.
- High reliability, long-term stable operation and can run at high ambient environment of 65°C.
- Automatic self start after power recovery
- Applicable for severe ambient environment, such as high temperature, high humidity atmosphere
- This series product can be used for enclosed area climate control such as wireless communication cabinet, battery cabinet, industry control cabinet etc.
scope:
- The cabinet air conditioner is endothermic cooling through compression refrigeration.
- In the confined cabinet, the heat issued by the inside equipment is transferred to the outside.
- The high temperature, dust and other dirty gas outside the cabinet will not enter into the cabinet.
- Thus it solves a series of problems caused by the fans during its cooling.
- The temperature in the cabinet can be kept at an ideal level which ensures a stable running of the electronic equipment
Outdoor cabinet air conditioner(WALL type) Model NO CGC-300 CQA-300 CPC-300 cooling capacity W 300 300 300 Btu/h 1023 1023 1023 power 220-240V/1PH/50Hz input power W 290 290 290 Grade of Protection inside IP54 outside IP34 Refrigergerant R134a Outside temp 15°C-52°C Inside temp 25°C-40°C temperature controller set point °C temp range25°C-40 °C factory settings :35°C Noise lever dB(A) 58 58 58 dimension W(MM) 392 392 392 H(MM) 719 719 719 D(MM) 125 125 125 Weight Kg 10 10 10
- Adoption of EU environmental protection refrigerant CFC-free access, security, environmental protection, green industry refrigeration products.
- According to pyrology Principles of design air inlet and outlet duct, cooling rapidly, evenly and effectively reduce energy consumption.
- Industry-specific design of ultra-thin form factor and electrical cabinets even more harmony and unity, save space.
- Comfort-type digital temperature controller, high-precision temperature control, mechanical temperature control.
- has a high-pressure, low-voltage, overheating and other over-current loading protection and alarm functions.
- Main components are passed CE, and 3C certification, high efficiency, long life.
- Adopting imported compressor and fan, using advanced refrigeration control technology, energy-efficient.
- Industrial & humanized design, easy installation, maintenance, safe and efficient.
- cyclic evaporation patented technology, non-condensing water design, save resources and improve efficiency.
...
Contact Us
- Shanghai Yuao Refrigerant Equipment Co., Ltd.
- Contact nameLynn Zhang
- Phone86-21-50323161,13816145342
- Address172 Xuanchun Road
