Cooling Power Server Cabinet

Name: Cooling Power Server Cabinet
Brand: YUAO
SKU: 141976812
Availability: InStock

US$ 400 - 1,896 MOQ: 100 Sets

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

YUAO

Model Number:

OC03-OC40

Shanghai Yuao Refrigerant Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name YUAO

Model Number OC03-OC40

cooling power server cabinet

Features :

Refrigerant: R134a
Digital control mode, can reach high accuracy.
The unit can work perfectly from -40 to +55 Degrees Celsius.
Keep the dust, oil fog and moisture from entering the internal of the equipments. IP23
The structure design makes the installation more flexible. And the unit can be installed perfectly in the side or outside wall of the equipment
The protective level of internal and external circulation is IP55, which can protect cabinet to avoid moisture, dust, water and also it can be installed inside and outside.
Digital temperature controlled and high precision of temperature control.
Unique condensate treatment system, no condensate discharge.
High reliability, long-term stable operation and can run at high ambient environment of 65°C.
Automatic self start after power recovery
Applicable for severe ambient environment, such as high temperature, high humidity atmosphere
This series product can be used for enclosed area climate control such as wireless communication cabinet, battery cabinet, industry control cabinet etc.

scope:

The cabinet air conditioner is endothermic cooling through compression refrigeration.
In the confined cabinet, the heat issued by the inside equipment is transferred to the outside.
The high temperature, dust and other dirty gas outside the cabinet will not enter into the cabinet.
Thus it solves a series of problems caused by the fans during its cooling.
The temperature in the cabinet can be kept at an ideal level which ensures a stable running of the electronic equipment

Outdoor cabinet air conditioner(WALL type)
Model NO		CGC-300	CQA-300	CPC-300
cooling capacity	W	300	300	300
cooling capacity	Btu/h	1023	1023	1023
power		220-240V/1PH/50Hz
input power	W	290	290	290
Grade of Protection	inside	IP54
Grade of Protection	outside	IP34
Refrigergerant		R134a
Outside temp		15°C-52°C
Inside temp		25°C-40°C
temperature controller set point	°C	temp range25°C-40 °C factory settings :35°C
Noise lever	dB(A)	58	58	58
dimension	W(MM)	392	392	392
	H(MM)	719	719	719
	D(MM)	125	125	125
Weight	Kg	10	10	10

Adoption of EU environmental protection refrigerant CFC-free access, security, environmental protection, green industry refrigeration products.
According to pyrology Principles of design air inlet and outlet duct, cooling rapidly, evenly and effectively reduce energy consumption.
Industry-specific design of ultra-thin form factor and electrical cabinets even more harmony and unity, save space.
Comfort-type digital temperature controller, high-precision temperature control, mechanical temperature control.
has a high-pressure, low-voltage, overheating and other over-current loading protection and alarm functions.
Main components are passed CE, and 3C certification, high efficiency, long life.
Adopting imported compressor and fan, using advanced refrigeration control technology, energy-efficient.
Industrial & humanized design, easy installation, maintenance, safe and efficient.
cyclic evaporation patented technology, non-condensing water design, save resources and improve efficiency.

...
