Solar Cool Server Rack Cabinet

Name: Solar Cool Server Rack Cabinet
Brand: YUAO
SKU: 141976798
Availability: InStock

Shanghai Yuao Refrigerant Equipment Co., Ltd.

US$ 400 - 1,896 MOQ: 100 Sets

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

YUAO

Model Number:

DC10

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name YUAO

Model Number DC10

solar cool server rack cabinet

equipment air conditioner,controller air conditioner,Auto control cabinet air conditioner

1.DC48V air conditioner,48VDC air conditioner,DC air conditioner
2.DC 48V motor , fan , compressor air conditioner ,DC48vcontroller

3.new product can be connect solar photovoltaic electric supply 48vdc system , wind turbine system , battery system .

4.used in electric cabinet , telemucation or communication enclosure cabinet , controller cabinet , battery cabinet cooling.

5.exculsive teachnical of DC48V cabinet air conditioner , and dc48v air conditioner , it is make 100% solar became ture.

Model NO	OC10
Input Power - Controller	-48VDC
Input Power - Cooling/Heating System	-48VDC ( -36VDC ~ -60VDC)
Control Panel	Embedded LCD
Language (Menu & User Munual)	Bilingual(EN&CHN)
External Fan Control - Emergency	Yes
External Fan Control - Free Cooling	Yes
External Fan Control - Hydrogen Discharging	Yes
External Air Conditioner On/Off Control	No
Cooling Capacity @ L35/L35	W	1150
Cooling Capacity @ L25/L35	W	N/A
Power Consumption @ L35/L35	W	450
Power Consumption @ L25/L35	W	N/A
Refrigerant		R134a
Internal Airflow	CMH	350
External Airflow	CMH	600
Heater (Optional)	W	N/A
Working Temperature Range	ºC	-15 to 55
Noise Level	dB(A)	65
Application		Outdoor
Protection from Dust, Water and Wind Driven Rain		IP55
Mounting Method		Door Mounted
Dimensions (Height x Width x Depth)	mm	1117×417×170
Weight	kg	45
CE & RoHS Compliant	Yes
