Precision Air Conditioner,precision Cooling Air Conditioner,precision Cooling Unit

Precision Air Conditioner,precision Cooling Air Conditioner,precision Cooling Unit thumbnail-1
Precision Air Conditioner,precision Cooling Air Conditioner,precision Cooling Unit photo-1
Negotiable MOQ: 100 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
YUAO
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Yuao Refrigerant Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name YUAO
Place of Origin Shanghai, China
Use Other, controller cabinet
Power Source Solar
Type Other, cabinet enclosure
Cooling/Heating Cooling/Heating
Certification CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, Other, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR, Other
Capacity (btu) 1023
COP 2.9
EER 2.85
Power (W) 195
Voltage (V) 48
Model Number OC-10

Specifications

precision air conditioner,precision cooling air conditioner,precision cooling unit,DC48V air conditioner,48VDC air conditioner,

precision air conditioner,precision cooling air conditioner,precision cooling unitprecision air conditioner,precision cooling air conditioner,precision cooling unit

precision  air conditioner,precision cooling air conditioner,precision cooling unit,air chiller,cooling unit,
2.DC 48V motor , fan , compressor air conditioner ,DC48vcontroller

3.new product  can be connect solar photovoltaic electric supply 48vdc system , wind turbine system ,  battery system .

4.used in electric cabinet , telemucation  or communication enclosure cabinet , controller cabinet , battery cabinet cooling.

5.exculsive teachnical of DC48V cabinet air conditioner , and dc48v air conditioner , it is make 100%  solar became ture.

Model NO  OC10
Input Power - Controller -48VDC
Input Power - Cooling/Heating System -48VDC ( -36VDC ~ -60VDC)
Control Panel Embedded LCD
Language (Menu & User Munual) Bilingual(EN&CHN)
External Fan Control - Emergency Yes
External Fan Control - Free Cooling Yes
External Fan Control - Hydrogen Discharging Yes
External Air Conditioner On/Off Control No
Cooling Capacity @ L35/L35 W 1150
Cooling Capacity @ L25/L35 W N/A
Power Consumption @ L35/L35 W 450
Power Consumption @ L25/L35 W N/A
Refrigerant   R134a
Internal Airflow CMH 350
External Airflow CMH 600
Heater (Optional) W N/A
Working Temperature Range ºC -15 to 55
Noise Level dB(A) 65
Application   Outdoor
Protection from Dust, Water and Wind Driven Rain   IP55
Mounting Method   Door Mounted
Dimensions (Height x Width x Depth) mm 1117×417×170
Weight kg 45
CE & RoHS Compliant Yes

....
