Specifications
1. Size:dia1500mmXmax600mmheight2. The size can be changed according to customer's need.3. Material: Carbon
JX GRAPHITE DISC
1. Place of Origin: China(mainland)
2. Product Name: graphite disc
3. Size: dia630-1530mm x max800mm height
4. The size can be changed according to customer's need.
5. Brand Name: J&X
6. Usage:It can be used Photovoltaic,single crystal silicon furnace,mono-crystal silicon furnace, making single crystal silicon and mono-crystal silicon.
Test Item | Unit | JXD1 | JXD2 |
Electric resistance | μΩm | 8.5 | ≤8.5 |
Bulk Density | g/cm3 | 1.72-1.74 | 1.70-1.72 |
Grain Size | mm | 0.8 | 0.8 |
Compressive Strength | Mpa | 37 | ≥35 |
Bending Strength | Mpa | 17 | ≥14.5 |
Porosity | % | 18 | ≤20 |
Ash Content | % | 0.11 | ≤0.2 |
C.T.E. | 100-6/°C | 2.5 | ≤2.5 |
Size | mm | Max Diameter 1500mm Max Height 600mm | |
JX MAIN MARKET ALL OVER THE WORLD
JX PRODUCTION SHOP
JX PROFESSIONAL TEST EQUIPMENTS
