Help CenterIndustrial Belt EP-250
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Model Number
EP-250
It is mainly used for industrial conveyer belts
| specification | EP-80 | EP-100 | EP-125 | EP-150 | EP-200 | EP-250 | EP-300 | EP-400 | |||||||||
| Item | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | |
| structure | D | 1000 /1 | 840 /1 | 1000/1 | 1680/1 | 1500/1 | 1680/1 | 1000/2 | 1260/2 | 1000/3 | 1260/2 | 1000/4 | 1260/2 | 1000/4 | 1260/2 | 1000/6 | 1260/3 |
| Density | Ends/10cm | 170+/-2 | 86+/-2 | 197+/-2 | 55+/-2 | 166+/-2 | 55+/-2 | 154+/-2 | 41+/-2 | 124+/-2 | 44+/-2 | 124+/-2 | 46+/-2 | 137+/-2 | 46+/-2 | 128+/-2 | 33+/-2 |
| Average breaking strength | N/mm | min105 | min55 | min137 | min78 | min160 | min65 | min200 | min70 | min247 | min80 | min310 | min90 | min343 | min90 | min445 | min100 |
|
Elongation under 10% load |
% | max1.5 | max1.5 | max1.5 | max 1.5 | max 1.5 | max1.5 | max1.5 | max1.5 | ||||||||
| Elongation at break | % | max14 | ma45 | max14 | max45 | max14 | max45 | max14 | max45 | max14 | max45 | max14 | max45 | max14 | max45 | max14 | max45 |
| Drying shrinkage | % | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 | max5.0 | max0.5 |
| Uneven drying shrinkage | % | max 10 | max 10 | max 10 | max 10 | max 10 | max 10 | max 10 | max 10 | ||||||||
| Adhesion strength | N/mm | min7.8 | min7.8 | min7.8 | min7.8 | min7.8 | min7.8 | min7.8 | min7.8 | ||||||||
| weight of absolute dry | g/m2 | 330+/-20 | 390+/-20 | 430+/-200 | 530+/-20 | 620+/-25 | 600+/-30 | 700+/-30 | 830+/-35 | ||||||||
| Gauge | mm | 0.5+/-0.05 | 0.6+/-0.05 | 0.60+/-0.05 | 0.70+/-0.05 | 0.8+/-0.09 | 1.0+/-0.1 | 1.1+/-0.1 | 1.4+/-0.20 | ||||||||
The width and length can be produced by client requirement.
