Help CenterHard Composite Graphite Felt (Carbon Fabric Based)
Related Products
-
Insulation Carbon Felt Operating Temperature:in the Air<400 Vacuum:>1500 In the Inert:>1250US$ 0.5 - 5MOQ: 100 Meters -
Rayon Graphite FeltNegotiableMOQ: 1 Piece
-
Pan-based Carbon Felt Operating Temperature:in the Air<400 Vacuum:>1500 In the Inert:>2500US$ 0.5 - 5MOQ: 100 Meters
-
Rigidized Graphite Felt (Carbon Fabric Based)NegotiableMOQ: 1 Piece
-
Hard Composite Carbon Felt (Carbon Fabric Based)NegotiableMOQ: 1 Piece
Specifications
1.Carbon content:>99%2.Bulk density:0.25-0.28
3.Thermal conductivity:0.2-0.3
4.Folding strength:1.75-3.2
Hard composite Graphite Felt (JX-HGF)6
The hard composite graphite felt is formed by graphite paper, PAN-based graphite felt, PAN-based carbon fabric by the process of curing sizing and secondary high temperature purification treatment. The material has high carbon content and superior in ablation resistance performance, thermal shock resistance performance, airflow washing proof performance and heat insulation performance. It’s mainly used in ultra-high-temperature high pressure vacuum sintering furnace, solar industry, semiconductor industry and electronic industry.
Property |
JXHGF Graphite foil based |
JXHGF Carbon fabric based |
|||
Item |
Unit |
Value |
Value |
||
Carbon content |
% |
≥99 |
≥99 |
||
Bulk density |
g/cm3 |
0.25-0.28 |
0.25-0.28 |
||
Thermal conductivity |
1150ºC W/(m.k) |
0.20-0.30 |
0.20-0.30 |
|
|
Folding strength |
MPa |
1.3-3.0 |
1.75-3.2 |
|
|
Bending strength |
MPa |
1.0-2.5 |
1.5-3.0 |
||
Crushing stress at 5% compression |
MPa |
0.4 |
0.7 |
||
Ash |
ppm |
≤200 |
≤200 |
||
Processing temperature |
ºC |
2500 |
|||
|
Operating temperature ºC |
In the air |
≤400 |
|||
Vacuum |
≥2200 |
||||
In the Inert atmosphere |
≥3200 |
||||
Board dimension |
Thick |
20-250mm |
|||
Width |
1000,1300mm |
||||
Length |
1000,1500,1800mm |
||||
Tube dimension |
Diameter |
Dia250-dia1600mm |
|||
Wall thick |
30-130mm |
||||
Height |
300-3000mm |
||||
