Waterproofing Material for Construction

Specifications

Excellent breather membrane,Breathable underlay for roofing, Eco-friendly to be completely recyclable.Antistatic , UV resistant

waterproofing material for construction| waterproof roofing membrane | sale waterproof membrane

1), Introduction of Waterproof Breathable Membrane

1.     Breathable Membrane is a water resistant membrane but with high vapour permeability, use as diffusion open roofing felts under pitched roof tile or vapour permeable barrier housewraps on timber frame walls
2.     Breather membrane functions as a weather-resistant barrier, preventing rain from getting into the roof or wall assembly while allowing water vapor to pass to the exterior.
3.     Breather membrane may also serve as an air barrier if it is sealed carefully at seams.
4.     Breathable Membrane have good "water resistance", good "water vapor permeability", and good "air barrier properties".



waterproofing material for construction| waterproof roofing membrane | sale waterproof membrane



2), Technical data of Breathabe Membrane

1. Products range: 80g,90g,100g,120g,140g,160g/m2.
2. Roll size: 1.5m x 50m
3. Water resistant : Class W1
4. SD-value: 0.02m
5. Vapor permeability: >2250g/m2/24h
6. UV resistant: >3month
7. Test to EN13859-1: Pass



waterproofing material for construction| waterproof roofing membrane | sale waterproof membrane

3), Advantage of Breathable Membrane:

1. CE mark available
2. High quality with competitive price
3. Excellent tensile and nail tear strength
4. Good flexibility and ductility
5. Light weight and thin, slip-resistant surface
6. Simple handling and easy to use
7. Anti-ageing: both heat and UV stable

   waterproofing material for construction| waterproof roofing membrane | sale waterproof membrane

4), Performance of Breathable Membrane:

     Resist liquid water passing through, but allow water vapour to pass through.



waterproofing material for construction| waterproof roofing membrane | sale waterproof membrane



5), Structure of Breathable Membrane:

     All SHANQUAN vapour permeable membranes are 3 layers thermal laminated:

     PP non-woven fabric + PE fuctional film + PP non-woven fabric



     Spun-bonded polypropylene non-woven fabric layers for protection and reinforcement.

     Micro-porous polyethylene film is the functional layer which is water-resistant but allow water vapour to pass through.
