ultrasonic humidifier Item No. AT-JS03A
Fog Volume: >3kg/h
Ways of Control: Humidity Control
Power Supply: 220V/110V
Power: 300w
External dimension: 48*30*52cm
Weight: 18kg
Applicable space: 50-100M3
Humidity: 70%-40%
Hole: 75mm(Single hole)
Device: auto humidifier control,water protect,automatic input water ,water filter
Specification:
Appearance is hanging outside wall
Stainless steel body
Spray plastic processing
Elegant appearance
Easily installation
Standard water inlet water drainage valve /overflow
Automatic input water and control water level
Digital humidity automatic control
Ste humidity control range during 1%-100%RH,control exact±3%RH,equipment can automatic work during the range, without people management
For the output pipe, it can reasonability distribute pipe according to the user ,distribute the spray jet in average ,seal up among the connector .
Inner adopt atomizing component and no water protection equipment, the atomizing particle size among1-10 um,can floating on the air in a long time ,
No mechanical drive ,no noise ,no pollution ,high atomizing efficiency ,energy saving when working .
Applying
Textile: control the humidity, eliminate static and falling dust
Paper-making: control the humidity of paper , eliminate static and falling dust
Computer room: humidity control and eliminate the static
Electrical industry: semiconductor factory humidity control and eliminate the static
Plastic industry and so on : humidity control and eliminate the static
Modle |
Capacity (kg/h) |
Power (AV) |
Spray nozzles (mm) |
Voltage(V/Hz ) |
Diameter of fog( m) |
N.W.(kg) |
Dimension(cm) |
Applicable space(m³) |
AOTE-JS03 |
3 |
300W |
75mm*1 |
220V |
1~5μ |
18 |
48*30*52 |
50~100 |
AOTE-JS06 |
6 |
600W |
110mm*1 |
220V |
1~5μ |
26 |
48*42*52 |
150~200 |
AOTE-JS09 |
9 |
900W |
110mm*2 |
220V |
1~5μ |
29 |
58*48*52 |
250~300 |
AOTE-JS012 |
12 |
1200W |
110mm*2 |
220V |
1~10μ |
32 |
68*48*52 |
350~400 |
AOTE-JS015 |
15 |
1500W |
110mm*3 |
220V |
1~10μ |
35 |
73*48*52 |
450~500 |
AOTE-JS030 |
30 |
3000W |
160mm*2 |
380V |
1~5μ |
58 |
73*65*55 |
900~100 |
AOTE-JS045 |
45 |
4500W |
160mm*3 |
380V |
1~5μ |
65 |
120*60*80 |
1200~1500 |
AOTE-JS090 |
90 |
6000W |
160mm*4 |
380V |
1~5μ |
72 |
195*80*80 |
2500~3000 |
Environment required: seal at normal temperature could reach 40%-70% humidity.
We could according to customer require to produce!
