Product Details
Place of Origin: | Shandong, China | Brand Name: | Jennyever | Model Number: | JGCL |
Product Description
Specifications
Bentonite Geosynthetic clay liners (GCL) consist of bentonite, woven between two geotextile layers. This lining mechanism uses
Composite GCLs HDPE sheets processing Packed GCLs rolls
Rolled GCLs side view Nonwoven geotextile side of GCLs Woven geotextile side of GCLs
Bentonite Geosynthetic clay liners (GCL) consist of bentonite, woven between two geotextile layers. This lining mechanism uses the properties of bentonite and the material to which it is bonded holds the clay in place.
Our GCLs specifications:
Type | GCLs A reinforced GCL consisting of a layer of natural sodium Bentonite between a woven and a non-woven geotextile which are needlepunched together | Composite GCLs A reinforced GCL consisting of a layer of natural sodium Bentonite between a woven and a non-woven geotextile which are needlepunched together and laminated to a thin flexible membrane liner. | ||
MODEL | JGCL | JSGCL | JHM-GCL | JHM-SGCL |
WIDTH | 5.8M | 2.9M | 5.8M | 2.9M |
LENGTH PER ROLL | 30M | 5M | 30M | 5M |
MASS WEIGHT OF BENTONITE | 3.6KG/SQM- 4.8KG/SQM | 3.6KG/SQM-4.8KG/SQM | 3.6KG/SQM-4.8KG/SQM | 3.6KG/SQM-4.8KG/SQM |
THICKNESS OF HDPE LINER | N/A | N/A | 0.1MM-0.3MM | 0.1MM-0.3MM |
CAPACITY OF 20’CTR | 3480SQM-4524SQM | 3480SQM-4524SQM | 3132SQM-4176SQM | 3132SQM-4176SQM |
