High Quality ISO Manufacturer Welded Wire Mesh (15 Years)
US$ 0.3 - 1
MOQ: 800 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Honsen
Model Number:
HSwm-1978
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Tianjin gb Q235 Black Slitting Flat Bar Steel Grating ManufacturesUS$ 10 - 30MOQ: 25 Pieces -
China Market Steel Structure Bar Grating / Galvanized Steel Floor / Galvanized Steel WalkwayUS$ 10 - 30MOQ: 25 Pieces
-
Galvanized Steel Bar Grating,galvanized Steel Grating Sheet,galvanizied Serrated GratingUS$ 10 - 30MOQ: 25 Pieces
-
Hot Dip Galvanized Serrated Flat Bar Steel Grating With Twisted Square Rod for Stairs and TreadsUS$ 10 - 30MOQ: 25 Pieces
-
China Factory Hot Sale Carbon Steel Bar Grating for Manhole CoverUS$ 10 - 30MOQ: 25 Pieces
Place of Origin
Hebei, China
Brand Name
Honsen
Model Number
HSwm-1978
Material
Other, Galvanized Iron Wire, Galvanized Iron Wire
Type
Welded Mesh
Application
Fence Mesh
Hole Shape
Square
Aperture
3/8''*3/8''------6''*6''
Wire Gauge
BWG14-----BWG23
WELDEDWire Mesh/Welded Mesh:
Mesh:1/4",3/8",5/8",1/2",3/4",1" to 6"
Gauge:#12--#24
Width:2' to 6', length specification can be at buyer's option.
Material: High quality low carbon steel wire,stainless steel wire,iron wire,Galavanized steel wire,PVC coated iron wire in blue,green,yellow and other colors.
Stainless steel welded mesh is the most popular products in the industrial world.
Packing in rolls, with waterproof paper:
PVC coated welded wire mesh is made of quality welded low carbon steel wire mesh galvanized before, then coated with PVC powder or PE powder. The coated layer is even, strong adhere siveness and bright luster with long live good anti-corrosive property. All kinds of colors can be coated according to customers' special requirements.
Packing in pallet:
Loading in container:
Varieties available: Electric galvanized hot-dipped PVC coated.
| Specification List of Welded Wire Mesh | ||
| Opening | Wire Diameter | |
| In inch | In metric unit(mm) | |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22, 23, 24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19, 20, 21, 22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16, 17, 18, 19, 20, 21, 22, 23 |
| 5/8" x 5/8" | 16mm x 16mm | 18, 19, 20, 21 |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16, 17, 18, 19, 20, 21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16, 17, 18, 19, 20, 21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14, 15, 16, 17, 18, 19 |
| 1" x 2" | 25.4mm x 50.8mm | 14, 15, 16 |
| 2" x 2" | 50.8mm x 50.8mm | 12, 13, 14, 15, 16 |
| Technical Note: 1, Standard roll length: 30m; width: 0.5m to 1.8m. 2, Special sizes available at request. 3, Packing: in waterproof paper in rolls. Custom packing available at request. | ||
| Galvanized Fencing Mesh | ||
| Opening | Wire Diameter | |
| In inch | In metric unit(mm) | |
| 2" x 3" | 50mm x 75mm | 2.0mm, 2.5mm, 1.65mm |
| 3" x 3" | 75mm x 756mm | 2.67mm, 2.41mm, 2.11mm, 1.83mm, 1.65mm |
| 2" x 4" | 50mm x 100mm | 2.11mm, 2.5mm |
| 4" x 4" | 100mm x 100mm | 2.0mm, 2.5mm |
| Technical Note: 1, Standard roll length: 30m; width: 0.5m to 1.8m. 2, Special sizes available at request. 3, Packing: in waterproof paper in rolls. Custom packing available at request. | ||
| PVC Coated Welded Mesh | ||
| Opening | Wire Diameter | |
| In inch | In metric unit(mm) | |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16, 17, 18, 19, 20, 21 |
| 3/4" x 3/4" | 19mm x 19mm | 16, 17, 18, 19, 20, 21 |
| 1" x 1" | 25.4mm x 25.4mm | 15, 16, 17, 18, 19, 20 |
| Technical Note: 1, Standard roll length: 30m; width: 0.5m to 1.2m. 2, Special sizes available at request. 3, Packing: in waterproof paper in rolls. Custom packing available at request. | ||
