Specifications
Fast-EZ High Ribbed FormworkStainless steel, Galvanized steel
Templete network, U pattern rib
16-year actory
ISO-9001
Fast-EZ High Ribbed Formwork
Fast-EZ High Ribbed Formwork, consisting of steel sheets formed into mesh and U pattern rib bone, will produce a surface with concrete which will bond directly to the next pour without any special treatment. The High Ribbed Formwork widely used in building construction to form retaining walls, columns, stopends, construction joints and used to support slab flooring.
High Ribbed Formwork Materials:
Fast-EZ High-Ribbed Formwork is manufactured from hot-dip zinc coated steel sheet to BS 2989 Z2 G275 standards.
High Ribbed Formwork Manufacture:
The mesh and ribs are formed on machines which first cut and press the mesh and then roll-form the ribs. At the same time the material is stretched to form an expanded mesh.
Specification:
Product | Thickness (mm) | Weight (kg) | Width (mm) | Length (mm) | Rib Height (mm) | Rib Distance(mm) |
Fast-EZ High Ribbed Formwork | 0.21 | 1.70 | 450 | 2200 | 14-20 | 90 |
0.23 | 1.90 | 450 | 2200 | 14-20 | 90 | |
0.30 | 2.48 | 450 | 2200 | 14-20 | 90 | |
035 | 2.90 | 450 | 2200 | 14-20 | 90 | |
0.40 | 3.30 | 450 | 2200 | 14-20 | 90 | |
0.45 | 3.70 | 450 | 2200 | 14-20 | 90 | |
0.50 | 4.10 | 450 | 2200 | 14-20 | 90 |
