Specifications
Carbide Bit Shank HammerLower energy consumption
Higher impact frequency
Easy and cheap maintenance
Long life, reliable
4 Inch Carbide Bit Shank Hammer /Downhole Drilling Hammer SD4:
1. 10 years manufacturing experience;
2. Certificate: ISO9001:2008
3. Material: Carbide
It is a kind of high air pressure DTH Hammer without footvalve, our newest design. It is also one of the most advanced DTH Hammers in the world.
It has the following advantages:
1. Out of the trouble of foot valve fracture and expansion and contraction.
2. Lower energy consumption and higher impact frequency. The drilling speed is 15%-30% higher than the one with foot valve.
3. Simple structure, reliable parts, long life, easy and cheap maintenance.
4. Lower air and oil consumption. The oil consumption is about 10% lower than the one with foot valve.
NSD4A DTH Hammer Technical Data
Length (Without Bit) | Weight (Without Bit) | External diameter | Bit Shank | Hole Range | Connection Thread | ||
1012mm | 40.00kg | 99mm | SD4 | 110-135 | API2 3/8Reg | ||
Working Pressure | Impact rate at 1.5Mpa | Recommended rotation speed | Air consumption | ||||
1.0Mpa | 1.8Mpa | 2.4Mpa | |||||
1.5-2.0Mpa | 30HZ | 25-40r/min | 6m³/min | 9m³/min | 14m³/min | ||
|
|
|
|
|
|
|
|
Item Description | Weight (kg) | Part Number |
1. Top Sub 2. O Ring of Top Sub 3. Check Valve 4. Spring 5. Air Distributor 6. Internal Cylinder 7. Piston 8. External Cylinder 9. Guided Sleeve 10. o Ring of Stop Ring 11. Stop Ring 12. Drive Chuck 13. Drill Bit | 6.50 0.01 0.35 0.05 1.50 2.10 8.50 15.30 1.30 0.005 0.20 4.00 9.80 | NSD4A01 NSD4A02 NSD4A03 NSD4A04 NSD4A05 NSD4A06 NSD4A07 NSD4A08 NSD4A09 NSD4A10 NSD4A11 NSD4A12 NSD4A13 |
Packing: Inner package with cartons,outer package with wooden case
Delivery: in 20 working days after receiving the advance payment
Our advantages:
We have advanced production equipments & talented researchers & technicians & rich experiences in R & D and production.
We use the best quality raw materials.
We adopt advanced production technology & strict testing procedure.
We passed ISO9001 quality management system certification.
We accept OEM manufacturing and produce on your design.
