Magnetic Electrical ac Contactor
Negotiable
/ Piece
1 Piece(Min. Order)
- Xi'an
- Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Kripal | |
| Model Number | UKC1 | Electricity Type | AC | |
| Number of Pole | 3 | Phase | 3 | |
| Main Circuit Rating Voltage | 690v | Main Circuit Rating Current | 800a |
Product Description
Specifications
1.reasonable price,punctual delivery,high quality2.certificate CE UL CB ISO9001
3.rated voltage 690V rated current up to 80
1.reasonable price,punctual delivery,high quality
2.certificate CE UL CB ISO9001
3.rated voltage 690V rated current up to 800A
| Specification | |||||||
| Model | UKC1-9 | UKC1-12 | UKC1-18 | UKC1-22 | UKC1-32 | UKC1-40 | |
| Rated operational current | Ie max AC-3 | 11A | 13A | 18A | 22A | 32A | 40A |
| Ie AC-1 | 25A | 25A | 40A | 40A | 50A | 60A | |
| Rated operational voltage | 690V | ||||||
| Pole No. | 3P,4P | ||||||
| Rated operational power in AC-3 | 220/240V | 2.5KW | 3.5KW | 4.5KW | 5.5KW | 7.5KW | 11KW |
| 380/400V | 4KW | 5.5KW | 7.5KW | 11KW | 15KW | 18.5KW | |
| 415/440V | 4KW | 5.5KW | 7.5KW | 11KW | 15KW | 22KW | |
| 500V | 4KW | 7.5KW | 7.5KW | 15KW | 18.5KW | 22KW | |
| 660/690V | 4KW | 7.5KW | 7.5KW | 15KW | 18.5KW | 22KW | |
| Thermal overload relays | class 10A | 0.1…22A | 0.1…22A | 0.1…22A | 0.1…22A | 4…40A | 4…40A |
| class 20A | 1.16…22A | 1.16…22A | 1.16…22A | 1.16…22A | 4...40A | 4...40A | |
| Model | UKC1-50 | UKC1-65 | UKC1-75 | UKC1-85 | UKC1-100 | UKC1-125 | UKC1-150 | UKC1-180 | UKC1-220 | |
| Rated operational current | Ie max AC-3 | 55A | 65A | 75A | 85A | 105A | 125A | 150A | 180A | 220A |
| Ie AC-1 | 80A | 100A | 110A | 135A | 150A | 150A | 200A | 230A | 260A | |
| Rated operational power in AC-3 | 220/240V | 15KW | 18.5KW | 22KW | 25KW | 30KW | 37KW | 45KW | 55KW | 75KW |
| 380/400V | 22KW | 30KW | 22KW | 45KW | 55KW | 60KW | 75KW | 90KW | 132KW | |
| 415/440V | 25/30KW | 30KW | 22KW | 45KW | 55KW | 60KW | 75KW | 90KW | 132KW | |
| 500V | 30KW | 33KW | 37KW | 55KW | 55KW | 60KW | 90KW | 110KW | 132KW | |
| 660/690V | 33KW | 33KW | 37KW | 45KW | 55KW | 60KW | 90KW | 110KW | 132KW | |
| Thermal overload relays | class 10A | 7…85A | 7…85A | 7…85A | 7…85A | 34...125A | 34...125A | 34...150A | 65…240A | 65…240A |
| class 20A | 7…85A | 7…85A | 7…85A | 7…85A | 34...125A | 34...125A | 34...150A | 65…240A | 65…240A | |
| Model | UKC1-330 | UKC1-400 | UKC1-500 | UKC1-630 | UKC1-800 | |
| Rated operational current | Ie max AC-3 | 330A | 400A | 500A | 630A | 800A |
| Ie AC-1 | 400A | 500A | 700A | 1000A | 1600A | |
| Rated operational power in AC-3 | 220/240V | 100KW | 110KW | 147KW | 200KW | 220KW |
| 380/400V | 200KW | 250KW | 295KW | 400KW | 450KW | |
| 415/440V | 200KW | 250KW | 295KW | 400KW | 450KW | |
| 500V | 200KW | 250KW | 355KW | 400KW | 450KW | |
| 660/690V | 200KW | 250KW | 355KW | 450KW | 475KW | |
| Thermal overload relays | class 10A | 200…630A | 200…630A | 200…630A | 200…630A | 800A |
| class 20A | 200…630A | 200…630A | 200…630A | 200…630A | 800A | |
Auxiliary contacts for 9-32A,1NC and 1NO instantaneous incorporated in the contactors, with add-on blocks common to the whole;
Auxiliary contacts for 40-150A, range comprising up to 4N/C or N/O instantaneous, up to 1N/O+1N/C time delay and up to 2N/O or N/C protected contacts and 2 screen continuity terminals;
Normalizing Electric is a leading automatic industrial equipment supplier, integrating scientific research, manufacture and trade.
| Type | UKC1-6M | UKC1-9M | UKC1-12M | UKC1-16M | ||
| Rated current at AC3 (A) | 6 | 9 | 12 | 16 | ||
| Rated working current (Ie)A | 5 | 7.5 | 10 | |||
| Conventional thermal current(Ith)A | 16 | 20 | 20 | 20 | ||
| AC-3 Use Group | 220V | 1.5 | 2.2 | 3 | 4 | |
| Control Power KW | 380/415V | 2.2 | 4 | 5.5 | 7.5 | |
| 440/500V | 3 | 4 | 5 | 5.5 | ||
| 660V | 3 | 4 | 4 | 4 | ||
| Rated working voltage (Ue)V | 380 660 | |||||
| Rated insulation voltage (Ui)V | 690 | |||||
| AC-3 | Electrical life (times) | 1million | ||||
| (6Ie Ie) | Operation frequency h-1 | 1800 | ||||
| AC-4 | Electrical life (times) | 0.2million | ||||
| (6Ie Ie) | Operation frequency h-1 | 300 | ||||
| Mechanical life | 1200 | |||||
