LG-PT400/PT400E Liquid Level Transmitter

Specifications

l Feature

Multi-connection forms, oil proof, waterproof, permeable and hard-wearing cable, safe , stainless structure. Explosion proof.

LG-PT400E can be specially used in some flammable environment.

l Technology Data

Measurement Range: 0 to 5 m H2O …… 0 to 500 m H2O

Accuracy: 0.5% F.S, 0.2% F.S ( including linearity, repeatability and hysteresis)

Output: 4~20mA, 1~5V,0~5V

Power supply: 24VDC±10%

Response Time: 10ms

Allowed over pressure: 2.5 times full scale

Long Term Stability: ±0.2% F.S per year

Compensated Temperature: from -10°C to +60 °C

l Application

It can be widely used in measuring pressure of water supply system, oil truck, reservoirs, pool.
