Digital Input Pressure Sensor

Specifications

It has adopted recent transducer and transmitter of International. It has advantage of low cost, high quality, mass production

Feature

LG-PT1100A pressure transmitter are developed .It has adopted recent transducer and transmitter of International. It has advantage of low cost, high quality, mass production. We use new Integration assembling technology to make our transmitter more stable and reliable.

l Technology Data

Measuring range: 0~5...50bar

Overload: 1.5 times of full scales

Accuracy: (Nonlinear +Repeatability+ Hysteresis)

±1%FS (10…40°C)

±2%FS ( 0…80°C)

±4%FS (-40…135°C)

Power supply: 4.5~5.5VDC (5~20VDC selectable)

Output: 0.5~4.5 VDC (proportion measuring)(1~5VDC)

Insulation: ≥10MΩ@50V

Response time: <10ms (0…99%)

Vibration / shock: 10g/5…2000HzX/Y/ZAxis/20g 11ms

Output mode: Three-wire

Electrical connection: Packard

Wetted parts & shell: stainless steel 1Cr18Ni9Ti, or brass.

Electromagnetic compatibility: electromagnetic transmit:EN50081-1/-2,electromagnetic sensitivity:EN50082-2

Process connection: G1/4”(Fluorine rubber Seal),3/8”-24UNF-2A,7/16”-20UN or M12×1.25 others on request.

IP rating: IP67           Weight: ≈45g
