Specifications
600mm wide6U, 9U, 12U, 15U, 18U and 22U 450mm deep
9U, 12U, 15U and 18U 600mm deep
19 Inch Wall Mounted Cabinets
A strong and robust 19” wall mounted cabinet. Fully ventilated, with a lockable steel framed glass door for safety and security. Quick release hinges allow for easy access to the cabinet for loading equipment and cables, lockable side panels allow access from both sides. Gland plate covers and cable strain relief positions are included on the top and bottom of the cabinet.
Features
600mm wide
6U, 9U, 12U, 15U, 18U and 22U 450mm deep
9U, 12U, 15U and 18U 600mm deep
Sliding 19” mounting angles front and rear
Standard ventilation top and bottom
Vented framed door with safety glass
Rear panel included
Easy one man installation
Heavy duty construction, 60kgs (UDL)
Comes completely assembled
Lockable side panels
Door opens 180°, left or right hinged
Built in cable strain relief positions.
Technical Specification
| Specification | |
| Top and base panel | 1.2mm |
| Side panels | 1.2mm |
| Framework | 1.2mm |
| 19” mounting angles | 1.5mm |
| Matching lock configuration on side panels | |
| on side panels Individual lock on front door | |
| Chassis support (L RAIL) Maximum load 20Kgs One pair included | |
| Material thickness | 1.2mm |
| UDL (Uniformly Distributed Load) | 60 kg |
| Degree of protection | IP20 |
Equipment Installation
Drill and mount wall bracket into the desired position
Minimum of 5mm screws Maximum of 8mm screws
Simply lift cabinet onto the bracket hooks
Secure to the bracket with internal screws
Ordering information
| Height | Depth | Width | Weight | Part No. |
| 6U | 450 | 600 | 20.5kg | WC0106 |
| 9U | 450 | 600 | 24kg | WC0109 |
| 9U | 600 | 600 | 28.5kg | WC0209 |
| 12U | 450 | 600 | 27.5kg | WC0112 |
| 12U | 600 | 600 | 32.5kg | WCO212 |
| 15U | 450 | 600 | 31kg | WC0115 |
| 15U | 600 | 600 | 36kg | WC0215 |
| 18U | 450 | 600 | 36.5kg | WCO118 |
| 18U | 600 | 600 | 42 kg | WCO218 |
