Welcome to Locwid Company
1. introduction
Our FRP Drainage Systems is machine made, use the excellent grade raw materials like fiberglass, polymer resin, and others. This ensures that our gutters could up to optimum performance to the end users.
Advantage of FRP Gutter:
anti-aging,wind resistant, the using life can up to 30 years.
FRP sheet has an excellent aging resistance performance, it has already made consensus in this area. Using FRP produces water collecting gutter, we can say that it takes full use of FRP material advantage, nothing goes to waste.
General steel gutter is limited within 3 meters, increased the Interface Construction cost and difficulties. Our gutter is produced by automatic continuous forming production line, no length limitation, reduces the number of interfaces, convenient to install and waterproof, effectively reduce construction cost. Chemical resistance performance is significantly better than inorganic materials such as stainless steel products.
2. Parameter
| No | Item | Technical data | Value | Result | Test method |
| 1 | Oxygen index (%) | ≥27 | 27.2 | pass | GB/T 2406-1993 |
| 2 | Horizontal Burning , (class) | FH-1 | FH-1 | pass | GB/T 2408-1996 |
| 3 | Vertical Burning ,(class) | FV-1 | FV-1 | pass | GB/T 2408-1996 |
| 4 | Tensile strength (MPa) | / | pass | GB/T 1447-2005 | |
| 5 | Flexural strength(MPa) | / | 263 | GB/T 1447-2005 | |
| 6 | Low temperature impaction | -40°C×1h | 10/0 pass | GB/T 8814-2004 | |
| 7 | transmittance % | / | 86.8 | GB/T 2410-1980 | |
| 8 | Water absorption % | / | 0.38 | GB/T 17657-1999 | |
| 9 | Barcol hardness | / | 51 | GB/T 3854-2005 | |
| 10 | Distortion temperature(1.81Mpa) | / | Above 260 | GB/T 1634-2004 | |
| 11 | Heat conductivity 25°C W/(m•k) | / | 0.648 | GB/T 10297-1998 | |
| 12 | Modulus of elasticity in static bending | Gpa | 6.1 | GB/T 1447-2005 | |
| 13 | Acid resistance | / | No change in surface | Refer to GB/T 4218-1984 | |
| 14 | Alkali resistance | / | No change in surface | Refer to GB/T 4218-1984 | |
| 15 | Loading performance,mm | ≤30 | 6 | pass | JC/T 562-1994 |
3. Photos
