Fireproof Material Aluminum Foil Bubble Heat Insulation Sheet

1:Structure :  Bubble Foil Insulation

AL / bubble + bubble(bubble also can be fire-retardant bubble)

Normal roll size: 1.2m x 40m/roll, 48" x 125'.

Normal Bubble size:4mm(height)*10mm(diameter)/7mm (height)*20mm(diameter)

Our Other Product structure belows:

1,AL+Single Bubble/Double Bubble+AL

2,AL+Single Bubble+PE

3,AL+Woven cloth/Scrim+Single bubble/Double bubble+Woven cloth/Scrim+A

Note:Woven cloth/Scrim can be replaced by the Fiber glass.

We can also replace the foil with metallized polyester foil for a more economical product.And the width can be 1.2m.

3.Characteristics:   Bubble Foil Insulation

· The bubble contains an air retention layer designed to provide increased strength and   puncture resistance and provide a greater reduction of heat transfer.

· The aluminum foil is an effective barrier against moisture, air currents and vapors.

· Aluminum foil reflective insulation, which can reflect up to 97 percent of the radiant energy that strikes it, has proven to be an outstanding radiant heat barrier.

· Keep summer heat out and winter heat in so to help keep houses cool in the summer and warm in the winter.

4.Application: Bubble Foil Insulation

Aluminum Foil With Double Bubble Thermal Can be used in residential construction in attics, walls,ceilings, and radiant floor heating applications. Also used in industrial/commercial buildings, agricultural buildings, and warehouses.
