Name: insulated fabric material
This item consists of PET-AL+EPE+WOVEN FABRIC (H: 2.5MM)etc multi-layers of obstruction material. It is an environment friendly product which has good heat preservation and insulation properties. The outer layer of PET provides excellent abrading and tears resistance. The middle layer of AL / XPE shows strong ability in barrier of moisture and oxygen, reduction and insulation of sound. The middle layer also has the advantages like reflecting light and heat and stopping the penetration of ultraviolet radiation.
Structure:PET-AL+EPE+WOVEN FABRIC
Main size:1.2m*100m
Usage:wall,roof,floor,etc
fireproof,bag
Features:
1.Cost-effective;
2.Glossy, with good visual effect;
3.Cuts and installs easier than fiber glass;
4.Keep warm in winter, hold cool in summer;
5.No odor and toxicity, environmentally- friendly,energy-saving.
Characteristics:
1.Resist 96-97% ultraviolet radiation;
2.Strong but clean, lightweight and flexible;
3.Easily stapled, nailed or glued into place;
4.Safe to handle, with no special clothing or breath equipment;
5.Heat reflection, heat insulation, sound insulation, anti-radiation, waterproof.
Applications:
1.Residential construction in attics, walls, ceilings, and radiant floor heating applications;
2.Industrial or commercial building;
3.Agricultural building;
4.Warehouses.
Technical parameters:
| PROPERTIES | Test Data |
| Thinkness | 3.5MM |
| Weight | 246G/M2 |
| Emissivity | 0.03-0.04COEF. |
| Thermal conductivity | 0.035W/MO |
| Apparent Density | 123KG/M3 |
| Reflectivity | 96-97% |
| Water Vapour Transmission | 0.012G/M2KPA |
| Corrosion | Doesn't generate |
| Tensile strenght(MD) | 0.77Mpa |
| Tensile strenght(TD) | 1.43Mpa |
Other product types:
1. AL/bubble/(AL);
2. AL/bubble +bubble/AL;
3. AL/ bubble/white PE anti flaming sheet;
4. AL/ white anti flaming bubble/AL with blue color;
5. AL/ white anti flaming bubble/ woven cloth/ AL;
6. AL/EPE/(AL);
7. AL/XPE/AL;
8. AL/non-woven cloth/(AL);
9. VMPET/EPE/(VMPET) etc.
