9501 Dn250 Stainless Steel Butterfly Valve
Product Specification:
1.Product Size: |
DN50-600 (2”-24”) |
2.Working Pressure: |
PN10-16( 150-230 PSI) |
3.Actuator |
Handle, worm gear, pneumatic or electric |
4.Standard: |
DIN,BS,ISO,ANSI, |
5.Connection: |
Flange type |
6.Working Temperature |
-15~150 Degree |
7.Body Material |
Cast iron,ductile iron, stainless steel or carbon steel available |
Construction and Material List:
Seat Temperature Ratings
Material |
NBR |
Neoprene |
EPDM |
Hypalon |
Viton |
PTFE |
|
Temperature Ratings |
°C |
-20~100 |
-40~100 |
-40~120 |
-32~135 |
-12~230 |
-50~200 |
°F |
-4~212 |
-40~212 |
-40~248 |
-25.6~275 |
10.4~446 |
-58~392 |
|
Products Feature:
1.High strength, light weight, good seal
2.Easy installation and maintenance;
2.Simple compact structure and quick on-off operation;
3.Small operation torque, energy-saving
4. Strict opening and closing test , long service life
5. Applicable for water, steem, food, oil,acid,etc.
Similar Products Picture:
Packaging:
1. Export standard carton for for Cast Iron Wafer Butterfly Valve
2. As per customer's request
Shipping:
Sea shipment
Air shipment
Courier shipment
Service Advantage:
1. 10 years manufacturing and exporting experience in agriculture field.
2. Professional technical support and solution by Chief Engineer.
3. Strict quality control system & team, high reputation in the market.
4. Quick, efficient and professional response within 24 hours, 14 hours online services.
5. Multilingual communication services (English, Spanish, French, Portuguese, Japanese etc.)
6. Full range of irrigation products for choice.
7. Accept sample order before mass production.
8. OEM/ODM services.
Quick Response:
NINGBO EVERGREEN IRRITECH CO., LTD.
Attn:Paul nie
Tel: +86-574-88107395
TradeManager: CN200834118
Skype: nbevergreen01
Send Inquiry to This Supplier
