Brief Introduction
Our large multi-level aluminium frame tent creates a perfect atmosphere for all kinds of your events and opens up new and interesting business opportunities for you.
Product Images
Key specifications
| Width | 15m,20m, 25m, 30m | Framwork material | hard pressed extruded aluminium 6082 T6 |
| Eave Height | 4.15m | Main profile | 288/123/9/4.5mm (4 Channel) |
| Ridge Height | N/A | Aluminium type: | European - Hard Pressed Extruded Structural Aluminium |
| Bay Distance | 5m | Eave connection | hot-dip galvanised DIN50976 |
| Wind loading | 102km/h | PVC Covering material | flame retardant according to DIN 4102, B1, M2; BS. 5438/7837; USA NFPA701 |
| Length can be extended unlimitedly. Custom design is available. | |||
The double-decker staircases also consist of anodized aluminium. Staircase landings as well as a large variety of staircases are available due to Huaye’s patented combination element.
Main Components
1) Roof Covers: Transparent, Translucent, block out PVC covers;
2) Sidewall: Soft PVC,Glass, ABS, Steel sheet, Sandwich panel;
3) Doors: Glass door, Sliding door, Rolling door, Double-wing door, Aluminum;
4) Lining Decoration: Roof lining, Wall Curtain, Lighting;
5) Flooring,Rain gutter,Ventilation system, Extended Ramps;
6) Transport and storage rack for doors
and many more...
Optional Accessories
- Lighting
- Linings
- Bar tensioning
- ABS walling system
- Glass walling system
- Single & double door units
- High peak roof conversions
- Lean-to-units
- Entrance porches
- Portal beams
- Ramp units
Certificate
Easy Installation
Payment Term and Lead Time
Payment Term: 30% deposit by T/T, the balance shall be made by T/T before shipment.
Lead time: 4 weeks
Packaging
1) aluminum profiles packed in film.
2) hardware packed in steel case.
3) roof and sidewall in PVC bag.
Project name: Columbia concert venue
Type of tent: Polygonal roof
Date: March, 2015
Size: 48 x 90 meters, 6 m side height, 13 m ridge height, (accomadated 6,000 people)
Project name: Olympic sailing center at Qiangdao, Shandong, China
Type of tent: A-shape tent
Date: Jan, 2015
Size: 30 x 35 meters, 4.0 m side height, 8.9 m ridge height
Our excellent customer put camouflage net to cover the roof.
Project name: China Car Rally 2015, basement tent for SKODA team
Type of tent: Double-layer tent
Date: May, 2015
Size: 7 x 20 square meters, 6.8 m side height (3.4 m each layer), 8 m ridge height
>> Huaye Products
Our extensive range of temporary structure systems provides the perfect framework for multiple applications. From the smallest Pagoda through to our innovative multi-level structure systems there are virtually no limits in terms of design, size, functionality and accessory options from which to select.
Pagoda tent A frame tent Large tent Curved tent Multi-sided tent Multi-level tent
About us:
>> About Us
HUAYE Tent Manufacture Co.,Ltd is an industry leading company specialising in the design, manufacture and supply of temporary and semi-permanent clear-span demountable tent systems. It supplies both the private and public sectors including the hospitality and events industry, the military, aid organisations, retail and general industry.
Our factory
Why Choose us:
- A leading manufacturer of marquee tent systems and industrial buildings.
- A diverse range of over 600 different temporary structures systems for multiple applications.
- State-of-the-art production facility able to produce up to 60,000m² of new structures per week.
- Components are CNC machined and finished by hand ensuring a consistent high quality finish.
- Dedicated technical team of CAD / CAM designers and stability engineers for custom projects.
- European Standards guarantee high quality, professionally engineered and fully certified structures.
- In- house technical sales force, strategically located worldwide providing local knowledge and support.
- Short production lead-times can always be achieved irrespective of the size of order.
- A globally recognised brand you can trust, providing complete peace of mind.
- Competitive pricing policy across all product lines – ensuring customer satisfaction.
