Name:roof heat shield insulation
FOil heat shield is a unique stong ,rigid materials and easy to install heavy duty sarking for use under cement and terracotta tiled roof however is not suitable for use under metal deck and slate tile roofing.
Foil heat shield is a heavy duty radiant barrier consisting of a layer of reinforced aluminium foil laminated with fire retardant adhensivbe to a heavy duty,high tensile and tear strength woven Poly Ethylene fabric.It is an economical foil suitable for use in bush fire prone areas and has a a green backing to eliminate glare during installation.
| Appearance | Silver heavy duty heat shield insulation |
| Structure | Aluminum foil/polyethylene/woven/polyethylene |
| Width | 1350mm |
| Length | 30m/60m |
| Grammage | 125gsm |
| Water Vapor Transmission | 0.015gsm/KPA |
| Tensile strength(MD) | 200N/25mm |
| Tensile strength(TD) | 250N/25mm |
| Bursting strength | 590N |
| Reflectivity | 91%-92% |
| Treatment | Fire retardant /printing logo/Perforated avaliable |
| Flammability Index | Class 1 (AS/NZS 1530.2 - 1993) |
| Thermal Performance | AS/NZS 4859.1 - 2002 |
Material structures(Heavy duty roof sarking foil insulation)
(1)Aluminum foil/pe/woven fabric
(2)Aluminum foil/pe/woven fabric/pe
(3)Aluminum foil/pe/woven fabnric/pe/aluminum foil
Advantages
1.Reflects at least 96% radiant heat
2.Non-toxic/Non-allergic
3.Durable and light weight
4.Does not being compressed,collapsed or not easy being damaged
5.Easy to be cut and install
6.Stop the growth of mold and mildrew
Heavy duty heat shield foil insulation
1.Roof sarking,wall wrap ,pipe insulation,roof heat insulation, waterproofing membrane
2.Travel mats,beach mats,camping mositure-proof pad
3.Car sunshade,car cover,aie conditioning covers,motocycle sunlight-proof cushions
4.Household appliances,precision instruments,high-grade porcelain and other crafts packing
A 20 container can load about 15-18tons metal roofing insulation
A 40HC can load about 22 tons metal roofing insulation
