Specifications

From small componentry, to long length fabrication We can provide you complete flexibility in your machining needs.

Cut to Length Aluminium Extrusion/Profiles

In-house high speed drilling capabilities are available.  We can accommodate all of your drilling needs.

Aluminium provides its own challenges regards production drilling and HBXDR has developed its expertise over many years and can provide a solution for all of your drilling requirements.

With a vastly diverse customer base, all with different sections and drilling requirements, our experience is equally as vast.

Whatever your drilling requirements, we can assist.





Product Name	Aluminum  Profile
Alloy	6063,6061,6005
Material	Aluminum
Surface Treatment	Mill,Anodized,painted etc
Temper:	T4, T5, T6 ,T66
Application:	Buildings,commercial,industrial



Billet’s Technical Data



1)Chemical composition

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Impurity	Al
6063	0.2-0.6	0.35	0.1	0.1	0.45-0.9	0.1	0.1	0.1	0.15	Rest
6061	0.4-0.8	0.7	0.15-0.4	0.15	0.8-1.2	0.04-0.35	0.25	0.15	0.15	Rest
6060	0.3-0.6	0.1-0.3	0.1	0.1	0.35-0.6	-	0.15	0.1	0.15	Rest
6005	0.6-0.9	0.35	0.1	0.1	0.40-0.6	0.1	0.1	0.1	0.15	Rest



2. Billet’s Mechanical property

Alloy	Temper	Tensile strength	Yield strength	Elongation
6063	T5	≥ 160Mpa	≥ 110Mpa	≥ 8%
	T6	≥ 205Mpa	≥ 180Mpa	≥ 8%
6061	T6	≥ 265Mpa	≥ 245Mpa	≥ 8%
