Home > Products > Construction Aluminium Profile > aluminum profiles for solar water heater
aluminum profiles for solar water heater
- 1800 Metric Ton / Metric Tons per Month
- Tianjin port China
- T/T
- shanghai common Aluminum Profile Aluminum Profile 6063 T5 Extrusion hot sale Aluminum Profile
- Aluminium Windows And Doors Profiles Wholesale Price Aluminium Doors And Windows Designs
- YIDUN Lighting Aluminum LED Channel Low-Profile Housing for 26mm PCB LED Strip Light with Complete Mounting Accessories
- custom aluminum profile extrusion wholesale aluminium section manufacturing machinery wholesale
- MV-EC4590 Custom pvc pp 68mm plastic industrial Hub end Cover for aluminum profile
- types made 4040/90x90 square plastic end covers for covering aluminum profiles
Product Details
Place of Origin: | Hebei, China | Grade: | 6000 Series | Temper: | T3-T8 |
Application: | Decorations | Shape: | Other, CNC Machining | Alloy Or Not: | Is Alloy |
Model Number: | DRJJ | Brand Name: | XDR |
Product Description
Specifications
From small componentry, to long length fabrication We can provide you complete flexibility in your machining needs.Aluminium Profile Aluminium Profile Aluminium Profile Aluminium Profile
Detailed Product Description
Product Name: | Aluminium Profile | Alloy: | 6063,6061,6005 |
Material: | Aluminum | Suface Treatment: | Mill Finished,Anodized ,Electrophoretic Coated,Powder Spray Coated |
Deep Process: | Milling, Drilling, Bending,Cutting | Temper: | T4, T5, T6 ,T66 |
Aluminium Profile / Assembly Line Profile
1.Alloy :6063,6061,6005 or according to customer' s choice
2.Material:Aluminum
3.Suface Treatment: Mill Finished,Anodized ,Electrophoretic coated,Powder spray coated,Fluorocarbon powder spray coated /PVDF Paint, Drawbench,Steel polished,Wood grain coated /Wooden transfer .
4.Deep process: Milling, Drilling, Bending,Cutting.
5.Application:
Industry Aluminum profile used in cars, trains machinery ,electronics, medical and other industrial filed . In terms of hardware, machinery, electromechanical parts, solar PV products, aluminum frames are adopt as important auxiliary materials. We also have aluminum profiles for radiators, fitness machinery, buildings, lighting instrument, windpipes, oil pipelines, for instance.
6.Color:clear, satin, bronze, black, golden, silver, other multicolor
7.Temper: T4, T5, T6 ,T66
Description:
Item | Customized Aluminum Industrial Profile |
Material | Alloy 6063, 6061,6005 or according to customer' s choice |
Temper | T3, T4, T5, T6 |
Surface | Anodize (clear, satin, bronze, black, golden, silver, other multicolor) , electrophoresis, powder coating, PVDF coating, wood grain painting, etc. |
MOQ | 1 ton. Usually 12 tons for a 20 feet container; 24 tons for a 40 feet container. |
Profile type | Industry Aluminum profile used in cars, trains machinery ,trailers ,electronics, medical and other industrial filed . |
Machining | High-precision machining 1. milling; 2. Drilling; 3. Bending; 4. Cutting ... |
Moulding | 1. Using our moulds, free; 2. Using customer' s drawing, mould fee need to be paid . |
Standard | Our Industrial Aluminium Profile Meet the China national standard GB/T5237-2004, GB/T6892-2000 |
FOB Port | Tianjin port China, etc. |
Applications:
Industry Aluminum profile used in cars, trains machinery ,electronics, medical and other industrial filed . In terms of hardware, machinery, electromechanical parts, solar PV products, aluminum frames are adopt as important auxiliary materials. We also have aluminum profiles for radiators, fitness machinery, buildings, lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1.Billet Technical Data
1)Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2).Mechanical property
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Competitive Advantage:
1)Engineering design and support.
2)Aluminum profiles deeply processing:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and whole inspection before package.
4)Good performance, product warranty for 15 years.
