Our aluminium profiles can be produced in different alloys from the 6000 series. The minimum purchase per profile is 500 kg and these profiles can be ordered in different lengths. The mechanical composition has been formulated in accordance with NEN-EN755-2 ( GB/T5237-2004, GB/T6892-2000 )and the dimensions of the profiles comply with standards NEN-EN755-9 or NEN-EN12020-2( GB/T5237-2004, GB/T6892-2000 ). The profiles have been divided into two categories:
Standard profiles: we possess a wide range of free die schemes for standard profiles.
Customised profiles
We supply profiles that have a theoretical weight of between 100 grammes and 10 kg per metre. You can request a price for an aluminium profile that you have designed yourself, but we can also help you to design the best possible aluminium profile to meet your needs. We can answer all your questions in the area of minimal wall thicknesses and explain your options in the area of extrusion. We can carry out strength calculations for you and assess snap joints.
Die schemes
Our die schemes are very attractive and can save you a great deal of money. For some structures, we can cut the mould free of charge. Please ask about the options, and we will be happy to explain them to you. If you wish to place a request, please send a request as complete as possible to
We are happy to be of service to you!
Detailed Product Description
Product Name: | Aluminium Profile | Alloy: | 6063,6061,6005 |
Material: | Aluminum | Suface Treatment: | Mill Finished,Anodized ,Electrophoretic Coated,Powder Spray Coated |
Deep Process: | Milling, Drilling, Bending,Cutting | Temper: | T4, T5, T6 ,T66 |
Aluminium Profile Aluminium Profile Aluminium Profile Aluminium Profile
Description:
Item | Customized Aluminum Industrial Profile |
Material | Alloy 6063, 6061,6005 or according to customer' s choice |
Temper | T3, T4, T5, T6 |
Surface | Anodize (clear, satin, bronze, black, golden, silver, other multicolor) , electrophoresis, powder coating, PVDF coating, wood grain painting, etc. |
MOQ | 1 ton. Usually 12 tons for a 20 feet container; 24 tons for a 40 feet container. |
Profile type | Industry Aluminum profile used in cars, trains machinery ,trailers ,electronics, medical and other industrial filed . |
Machining | High-precision machining 1. milling; 2. Drilling; 3. Bending; 4. Cutting ... |
Moulding | 1. Using our moulds, free; 2. Using customer' s drawing, mould fee need to be paid . |
Standard | Our Industrial Aluminium Profile Meet the China national standard GB/T5237-2004, GB/T6892-2000 |
FOB Port | Tianjin port China, etc. |
Applications:
Industry Aluminum profile used in cars, trains machinery ,electronics, medical and other industrial filed . In terms of hardware, machinery, electromechanical parts, solar PV products, aluminum frames are adopt as important auxiliary materials. We also have aluminum profiles for radiators, fitness machinery, buildings, lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1.Billet Technical Data
1)Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2).Mechanical property
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Competitive Advantage:
1)Engineering design and support.
2)Aluminum profiles deeply processing:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and whole inspection before package.
4)Good performance, product warranty for 15 years.
