One Way Vision Film

Name: One Way Vision Film
Brand: huasheng
SKU: 141845642
Availability: InStock

Negotiable MOQ: 4000 Square Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

huasheng

Model Number:

one way vision film

Zhejiang Huasheng Warp Knitting New Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name huasheng

Model Number one way vision film

Material Other, PVC

Specifications

One-way vision : the surface film is made of the PVC coat of equality.

One-way vision : the surface film is made of the PVC coat of equality,black glue bacikside, 160gsm release paper.

Specification	Description
PVC	Type	PVC Calendered monomeric soft PVC film
	Thickness	150±10um
	Color Code	Ceramic white
	Back	Black coating
	Shrinkage	0.80%
	Surface Tension	30dn/cm
	Opacity	>99%
	Holes No.	Average 130/sq
	Hole Diameter	1.6mm
	Distance Between Holes	2.4mm
	Hole Space	50%
Adhesive	Type	Clear solvent based removable pressure sensitive glue
	Weight(g/)	28±3
	Adhesion Temperature	15~40
	180°Peeling Force	5N/25mmGB2792-81China National Standard
	Initial Adhesion-Ball Tack	5#Steel Ball GB4852-84China National Standard
	Holding Power	800minGB4854-84China National Standard
	Removable Durability	1,23~25,50~60% One year cleanly removable glue on clean
		glass surface at temperature of 23~25 and RH of 50~60%
Liner Paper	Type	Coated paper (Replacement Liner)
	Color	White
	Weight	160g±5g/
	Release Force	0.4~1N/4cm
Storage Period	12225055 12 months under ordinary condition at temperature of 22 and relative humidity of 50-55%
Application	One way vision media used in digital and silk screen printing machines for signage display,
Application	vehicle graphics , subway and glass walls of building
	MimakiRolandVutekHP Scitex38~43
Compatibility of	Media is suitable for all solvent and eco solvent digital printers with heating system including
machines and ink	Phaeton,Infiniti, Mimaki , Roland, Vutek and HP Scitex.
	Inks should be the original inks from the printer manufacturers. The best printing temperature is
	38-43.
