U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight

U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight thumbnail-1
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight thumbnail-2
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight thumbnail-3
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight thumbnail-4
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight thumbnail-5
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight photo-1
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight photo-2
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight photo-3
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight photo-4
U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm Thickness For Roofing Skylight photo-5
US$ 5.1 - 5.9 MOQ: 1000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Lixin or OEM
Model Number:
LGU4HS
Contact Supplier Request Quote Chat Now
Haining Gensin Plastic Sheet Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Lixin or OEM
Model Number LGU4HS

Specifications

Hollow Polycarbonate Sheets
1.100% Virgin Lexan or Bayer raw material
2.UV Coating
3.10 Years Warranty
4.U Shape Connector

U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight





Product Description

Lixin 8-wall Rectangle-structure locking-design sheet is ideal for long-term application in high loads and large-span systems. It offers exceptional thermal insulation and impact strength at a very light weight. Standing Seam designs accommodates expansion and contraction,eliminating water leakage problems. Available in 16-30mm thicknesses.





Structure Display

  U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight

U-lock 8-wall R-Structure Hollow Sheet Data



Structure





Item No.



Thickness

(mm)



Weight

(kg/sqm)

Stand Width(mm)

Rib Distance

(mm)



U-value

(w/sqm*k)



UV Side



LT(%)

Clear

LT (%) Bronze



LT(%)

Opal White

LT (%)

 Green



LT(%)

Blue



U-lock 8-wall R-

Structure

 LGU8RS16T3400

16

3.4

 1040

6

1.56

1/2

50

 20  20
LGU8RS20T4100

20

4.1

1040

6

1.51

1/2

49

19

  19


LGU8RS25T4600

25

4.6

1040

6

1.45

1/2

48

18

  18


LGU8RS30T5200

30

5.2

1040

6

1.38

1/2

46

17

 17




Technical Data Of PC Sheet
No. Characteristics Unit Data
1 Impact Strengt J/m 850
2 Light Transmission % According to the Thickness and Color
3 Specific Gravity g/m³ 1.2
4 Coefficient of Thermal Expansion mm/m℃ 0.065
5 Service Temperature ℃ -40 to 120
6 Heat Conductivity W/m²℃ 2.3 to 3.9
7 Tensile Strength N/mm² >60
8 Flexural Strength N/mm² 100
9 Modulus Of Elasticity MPa 2400
10 Tensile Stress At Break MPa >65
12 Elongation At Break % 100
13 Specific Heat KJ/kg K 1.17
14 Heat Deflection Temperature ℃ 140


Advantage


1

Light  weight

2

Excellent  impact  resistance

3

Good light  transmission

4

Good weather resistant  and UV protection

5

Sound  and  heat  insulation

6

Simple process and installation

7

Grade B1 fire resistance

8

An engineering plastic of excellent  integration capability





 Product Show

             U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing SkylightU Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight





Color Selection

U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight



Project Show

 Polycarbonate sheet has high light transmittance, good impact resistance,  good thermal insulation, easy installation, and widely used in construction and decoration.

   U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight



Company Information

HAINING GENSIN Plastic sheet co., ltd  is the largest manufature of polycabronate sheets in east china,  establshed since 2003, located in haining(between Hangzhou and Shanghai ).

U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight





Packaging & Shipping

For solid sheets, PE film on both sides, and  packed on wooden pallets.





Fair Show

 Every year we will take an active part in many related building materials exhibition and advertising exhibition



U Shaped Mutiwall Hollow Polycarbonate Sheets 8-wall Layers 16-20-25-30mm thickness For Roofing Skylight





FAQ

1,HOW TO CHOOSE THE SUITABLE SHEETS FOR US?



   If you are not sure that which kind of sheet that you will use,you can contact us,and tell us your application,our sales will introduce the suitable sheets for you,and we will give you more information about the sheets



2,WHAT'S THE PRICE OF THE SHEETS?



  Please contact us,and inform your sheets' thickness,size,quantity and other requirements,our sales will quote our best price to you.Also you can send us your project detail drawing,we will check and quote to you.



3,THERE IS NO SHEETS AND PROFILES THAT I WANT?



 If that,you can send us your special sheets or profiles drawing with details,we can quote to you.
