Haining Gensin 1mm Polycarbonate Solid Sheet Opal 1220*2440mm

Specifications

1mm Polycarbonate Solid Sheet
1.Light and durability
2.Excellent light transmission
3.High impact strength

 Haining Gensin 1mm Polycarbonate Solid Sheet Opal 1220*2440mm



Lixin Polycarbonate Solid Sheets' weight is less than half of the glass, and has the high impact strength. Gensin Polycarbonate Solid Sheet can be cold bend, processed and hot molding. It is widely used in construction and decorations.





Specifications:
Thickness: 0.8 to 20mm
Maximum width: 2,100mm
Length: any dimension
Specific gravity: 1200kg/cbm
Colors: clear, blue, green, opal, brown,bronze,etc.



Technical features:
Impact strength: 850J/m ,the impact strength of solid PC sheets is 250 times
that of glass, 20-30 times of PMMA sheet
Light transmission: 80%-90% for different thickness of clear color

UV resistance:with our 50μm thickness UV layer ,the sheet can filter 99% ultraviolet radiation in sunlight
Specific gravity: 1.2 g/cm
Coefficient of thermal expansion: 0.065 mm/m^oC

Temperature: -40^oC to 120^oC

Heat conductivity: 2.3-3.9 W/m^{2   oC}
Tensile strength: >60N/mm²
Flexural strength: 100N/mm²
Modulus of elasticity: 2,400mPa
Tensile street at break: >65mPa
Elongation at break: >100%
Specific heat: 1.16J/kg^k
Heat deflection temperature: 140^oC
Soundproof index:6mm--29dB,8mm--31dB,10mm-32dB 12mm--34dB





Thickness    (mm)	Standard width      (mm)	Standard length       (mm)	Standard gravity     (kg/sqm)	Standard  colors
1.5	1200-2100	6000mm    4mm≥no limited	1.8	Clear Green-blue Blue Green Brown opal
1.8			2.16
2			2.4
2.5			3.0
3			3.6
4			4.8
5			6.0
6			7.2
8			9.6
10			12
12			14.4



Appliction

• Lighting
• Indoor windows and doors
• shop show window
• Awning, carport
• Advertising panel
• Sound barrier
