2.5mm Crystal Diamond polycarbonate Sheet/ Polycarbonate Embossed Sheet
Gensin Embossed Sheet has many texture options including diamond, raindrop, leather, frosted and prismatic pattern etc.Embossed Sheets are solid polycarbonate sheets with a texture on one surface. The purpose of texturing is to provide light diffusion and prevent see-through vision as deemed necessary for a variety of applications. These textures enable the diffusion of natural light streaming in along with ascertaining uniform dispersion of light over a large area.
Applications of embossed polycarbonate sheet
• Bathroom
• Glazing, Lighting
• Partition, Shelters
• Canopy Roofing
• Interior Designing
Item |
Property |
Value |
|
Polycarbonate Sheet |
Light weight |
Density:1.2Kgs/cbm, half weight of glass |
Light transmission |
80%-90% for different thickness of clear color |
|
UV resistance |
50μm UV layer, filter 99% ultraviolet radiation in sunlight |
|
Coefficient of thermal expansion |
0.065 mm/m°c |
|
Service temperature |
-40°c to 120°c |
|
Heat conductivity |
2.3-3.9 W/m2℃ |
|
Tensile strength |
>60N/mm² |
|
Flexural strength |
100N/mm² |
|
Tensile street at break |
>65mPa |
|
Heat deflection temperature |
140°c |
|
| High Impact strength |
impact strength is 250 times of glass,
20-30 times of PMMA sheet
|
|
| Fire Rating |
B1/V2, self-extinguish within 60 seconds |
| Basic Information | |
| Material | 100% Sabic/Bayer virgin material |
| UV stability | 50micron; one side or two sides |
| Guarantee | 10 years |
Colors available |
normal color: clear, opal white, blue, green, gray, brown, red, glittering colors, etc. |
| Special color: silver, opaque colors, metallic colors, diffusion colors, pearl colors, matte colors, etc | |
| Package | PE film on smooth side, packed in roll or on pallets. |
| Delivery time | 7-10 working days against your deposit |
| Payment | 30% T/T in advance, 70% against the copy of BL |
| Port of loading |
Shanghai or Ningbo |
