Grade A UV Protector Bronze Colored Embossed Polycarbonate Sheet,Virgin Plastic Granules Sheet,Embossed Panel
Lixin polycarbonate embossed sheet is a branch of polycarbonate solid sheet.it applies to in door instalation,indoor partition,advertising industry and mechanical manufacturing industry because of specail particle appearnce of the prism or frosted glass.Lixin polycarbonate embossed sheet has features of Lixin solid sheet:less weight,impact resistance,high light transmission and various colors.
Thickness(mm) | Standard size (mm) | Min bend radius (mm) | Specific gravity (g/cm3) | Standard colors |
1.8 | 1200-2100 | 270 | 1.2 | Clear, green, blue, brown, smoky gray |
2 | 300 | |||
2.5 | 375 | |||
3 | 450 | |||
4 | 600 | |||
5 | 750 | |||
6 | 900 | |||
7 | 1050 | |||
| 8 | 1200 | |||
| 9 | 1350 | |||
| 10 | 1500 |
| Technical Data Of PC Sheet | |||
| No. | Characteristics | Unit | Data |
| 1 | Impact Strengt | J/m | 850 |
| 2 | Light Transmission | % | According to the Thickness and Color |
| 3 | Specific Gravity | g/m³ | 1.2 |
| 4 | Coefficient of Thermal Expansion | mm/m℃ | 0.065 |
| 5 | Service Temperature | ℃ | -40 to 120 |
| 6 | Heat Conductivity | W/m²℃ | 2.3 to 3.9 |
| 7 | Tensile Strength | N/mm² | >60 |
| 8 | Flexural Strength | N/mm² | 100 |
| 9 | Modulus Of Elasticity | MPa | 2400 |
| 10 | Tensile Stress At Break | MPa | >65 |
| 12 | Elongation At Break | % | 100 |
| 13 | Specific Heat | KJ/kg K | 1.17 |
| 14 | Heat Deflection Temperature | ℃ | 140 |
Advantage | |
1 | Light weight |
2 | Excellent impact resistance |
3 | Good light transmission |
4 | Good weather resistant and UV protection |
5 | Sound and heat insulation |
6 | Simple process and installation |
7 | Grade B1 fire resistance |
8 | An engineering plastic of excellent integration capability |
Applications( polycarbonate embossed sheet ):
1), Roofing skylight for office building,department store, hotel, stadium, school. |
2), Soundproof shields on express ways. |
3), LED diffused, Advertising lamp boxes, sign board.Telepohne booths. |
4), Anti-riot shield, bullet resistant material, Bank ATMs. |
5), Agricultural greenhouses, zoos, botanical gardens. |
6), Swimming Pools roofing/cover/sheet |
7), Lighting for corridors, balcony, passages and subway entries, walkways. |
8), Walls, roofs,windows,screens,shower enclosure. |
9), Instrument and machine windscreen |
Product Show
Gensin Polycarbonate Sheets are made from 100% virgin Sabic Lexan or Bayer Makrolon Raw PC Resin
For solid sheets, PE film on both sides, and packed on wooden pallets.
Every year we will take an active part in many related building materials exhibition and advertising exhibition
1,HOW TO CHOOSE THE SUITABLE SHEETS FOR US?
If you are not sure that which kind of sheet that you will use,you can contact us,and tell us your application,our sales will introduce the suitable sheets for you,and we will give you more information about the sheets
2,WHAT'S THE PRICE OF THE SHEETS?
Please contact us,and inform your sheets' thickness,size,quantity and other requirements,our sales will quote our best price to you.Also you can send us your project detail drawing,we will check and quote to you.
3,THERE IS NO SHEETS AND PROFILES THAT I WANT?
If that,you can send us your special sheets or profiles drawing with details,we can quote to you.
