2mm Transparent LED light Cover / Prism Polycarbonate Sheet
Gensin prism polycarbonate sheet, the special optical prism design, makes the sheet even with clear color also can scatter the light. It is made from 100% Sabic or Bayer virgin material.The light transmittance is almost close to 90%. Compared with PMMA sheet, polycarbonate sheet is much higher impact strength, better fireproof.
| Item | Prism size | Sheet Thickness | Standard Size |
| Prism PC sheet | 2mm | 2-10mm | 1220*2440mm |
Datasheet:
Item | Property | Value |
Polycarbonate Solid Sheet | Light weight | Density:1.2Kgs/cbm, half weight of glass |
Light transmission | 80%-90% for different thickness of clear color | |
UV resistance | 50μm UV layer, filter 99% ultraviolet radiation in sunlight | |
Coefficient of thermal expansion | 0.065 mm/m°c | |
Service temperature | -40°c to 120°c | |
Heat conductivity | 2.3-3.9 W/m2℃ | |
Tensile strength | >60N/mm² | |
Flexural strength | 100N/mm² | |
Tensile street at break | >65mPa | |
Heat deflection temperature | 140°c | |
| High Impact strength |
impact strength is 250 times of glass,
20-30 times of PMMA sheet
| |
| Fire Rating | B1/V2, self-extinguish within 60 seconds |
Applicaton of prism polycarbonate sheet:
1.Advertising light boxes, signs, outdoor
billboards, LED lighting, Guides system, light cover
2.Indor windows and door
3.Indoor partition
4.Advertising panel
2mm Prism: min tickness 2mm; Clear color/ Diffusion White; custom size
Test machine for light transmittance and haze.
