ISO4427 PE/HDPE pipe&fittings for water supply with high quality and lowest price
PE Pipe Specificiation
| PN | 0.4Mpa | 0.6Mpa | 0.8Mpa | 1.0Mpa | 1.25Mpa |
| SDR | SDR33 | SDR21 | SDR17 | SDR13.6 | SDR11 |
| OD | Thickness | Thickness | Thickness | Thickness | Thickness |
| 20 | 2.3 | ||||
| 25 | 2.3 | ||||
| 32 | 3.0 | ||||
| 40 | 3.0 | 3.7 | |||
| 50 | 3.7 | 4.6 | |||
| 63 | 3.6 | 4.7 | 5.8 | ||
| 75 | 4.5 | 5.6 | 6.8 | ||
| 90 | 4.3 | 5.4 | 6.7 | 8.2 | |
| 110 | 5.3 | 6.6 | 8.1 | 10.0 | |
| 125 | 6.0 | 7.4 | 9.2 | 11.4 | |
| 160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 |
| 180 | 5.5 | 8.6 | 10.7 | 13.3 | 16.4 |
| 200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 6.9 | 10.8 | 13.4 | 16.6 | 20.5 |
| 250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 |
| 280 | 8.6 | 13.4 | 16.6 | 20.6 | 25.4 |
| 315 | 9.7 | 15.0 | 18.7 | 23.2 | 28.6 |
| 355 | 10.9 | 16.9 | 21.1 | 26.1 | |
| 400 | 12.3 | 19.1 | 23.7 | 29.4 | |
| 450 | 13.8 | 21.5 | 26.7 | 33.1 | |
| 500 | 15.3 | 23.9 | 29.7 | 36.8 | |
| 560 | 17.2 | 26.7 | 33.2 | 41.2 | |
| 630 | 19.3 | 30.0 | 37.4 | ||
| 710 | 21.8 | 33.9 | 42.1 | ||
| 800 | 24.5 | 38.1 | 47.4 |
Hdpe Pipe Specification
| PN | 0.6MPa | 0.8MPa | 1.0MPa | 1.25MPa | 1.6MPa |
| SDR | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 |
| OD | Thickness | Thickness | Thickness | Thickness | Thickness |
| 20 | 2.3 | ||||
| 25 | 2.3 | ||||
| 32 | 3 | ||||
| 40 | 3 | 3.7 | |||
| 50 | 3.7 | 4.6 | |||
| 63 | 3.8 | 4.7 | 5.8 | ||
| 75 | 4.5 | 5.6 | 6.8 | ||
| 90 | 4.3 | 5.4 | 6.7 | 8.2 | |
| 110 | 4.2 | 5.3 | 6.6 | 8.1 | 10 |
| 125 | 4.8 | 6 | 7.4 | 9.2 | 11.4 |
| 160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
| 180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
| 200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
| 250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
| 280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
| 315 | 12.1 | 15 | 18.7 | 23.2 | 28.6 |
| 355 | 13.6 | 16.9 | 21.1 | 26.1 | |
| 400 | 15.3 | 19.1 | 23.7 | 29.4 | |
| 450 | 17.2 | 21.5 | 26.7 | 33.1 | |
| 500 | 19.1 | 23.9 | 29.7 | 36.8 | |
| 560 | 21.4 | 26.7 | 33.2 | 41.2 | |
| 630 | 24.1 | 30 | 37.4 | ||
| 710 | 27.2 | 33.9 | 42.1 | ||
| 800 | 30.6 | 38.1 | 47.4 |
Features
1.Nontoxic:
PE pipe material nontoxic, tasteless,it belongs to green building materials, never scaling,
which can effectively improve the water quality.
2.Corrosion resistance:
High resistance to attack from various types of chemicals. No electrochemical corrosion.
3.No Leakage:
PE pipe is connected in the ways of butt fusion, socket fusion and electrofusion and the
strength of joint point is higher than tube itself .
4.higher flow capacity:
The Smooth inner wall is easy for pipeline transportation .Under the same condition
delivery capacity can be increased by 30%.
5.Convenient for construction and installation:
PE pipe could be installed in a variety of trenchless ways, so it is very convenient for
construction and installation.
6.Lower system and maintenance costs:
PE pipe is not only convenient to transport and install, but also reduce the worker’s
labor intensity and improve work efficiency.
7.Longevity:
50 years under pressure use.
8. Recycled and Environment-friendly
Application:
1.Urban tap water pipe network system
Large diameter PE pipe, health non-toxic, not fouling, more suitable for urban water supply main conduit and buried tube, safety, hygiene, convenient construction.
2.Replaceable cement tubes, iron pipe and steel tube
Used for old nets renovation project, don’t need large area excavation, low cost, can be widely used in old town of pipe network reconstruction.
3.Industrial materials duct
Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and papermaking, metallurgical and other industrial raw material conveying pipe.
4.Landscaping water supply network
Landscaping need lots of water pipe, PE pipe toughness and low cost, make it become the best choice.
5.Sewage discharge pipes
PE pipe have unique corrosion resistance, can be used in industrial wastewater, sewage discharged pipe,low costs and maintenance costs .
6.Ore, mud transfers
PE pipe has high resistance to stress and wear resistance, can be widely applied in conveying ore, coal ash and river bait-casting mud.
7. Agricultural irrigation pipe
PE pipe inside sleek, great flow, cross road construction, good impact resistance, it is the ideal tool for agricultural irrigation.
HDPE SOCKET AND BUTT FUSION PIPE FITTINGS
Packaging
1. Export standard carton
2. As per customer's request
Shipping:
Sea shipment
Air shipment
Courier shipment
In our factory we have 100 workers, 15 years experience, ISO, CE certificated, soon reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Q1.How to get free samples ?
A: Send your address, your telphone number , post code ,and express account number to our mail box .and told us which model of samples you need .
Q2.Who pay for the express cost ?
A: We can support you free samples each model 1-3 pcs ,as to the express you pay firstly,after place order we will return the freight to you.
Q3.What is your packing?
A: Usually plastic bags,carton, can be packed as your require.
Waiting your kindly enquiry
