Diameter pe Pipes for Water Supply 12 SDR 11 PN 16 hdpe butt fusion fittings /pe
1.contact method
Skype: stsylucy
Tel: 86 0311 86125138
2.Product Overview
1)Material:hdpe80 or hdpe100
2)Size:dn25mm-dn1200mm,en4.2mm-en70.6mm
3)Standard:GB/T 13663-2000
4) Form supplied:
5.5 meters and 11.6 meters straight length (all size)
50 or 100 meters coil length (dn20~dn63)
5) Pressure rating:0.4MPa,0.6 MPa,0.8 MPa, 1.0MPa, 1.25 MPa, 1.6MPa
6)Fitting :injection or welded
7)Connection:socket fusion joint ,butt fusion joint,electro fusion joint,flanged joint
3.Advantage:
1)Non-toxic: no heavy metal additives ,would not be covered with dirt or contaminated by bacterium
2)Corrosion Resistant: resist chemical matters and electron chemical corrosion
3)Low Flow Resistance: smooth interior walls and low friction
4)Excellent Flexibility: can be supplied in coil
5)Easy installation: light weight and handed friendly
6)Longevity: more than 50 years under proper use
7)Various Joint Availability: socket fusion joint, butt fusion joint, electro fusion joint and transition joint
4.Applications
1 )Municipal water supply
2)Commercial & Residential water supply
3)Industrial liquids transportation
4)Sewage treatment
5. Physical Properties
Properties |
Typical Value |
|
Specific Gravity, g/cm3(20°C) |
0.941~0.965 |
|
Longitudinal Reversion, %(110°C) |
≤3 |
|
Oxidation Induction Time, min(200°C) |
≥20 |
|
Extension Rate at Break,% |
≥350 |
|
Hydraulic Pressure Test (PE100) |
20°C,100h, Hoop Stress is 12.4MPa |
No Failure |
80°C,165h, Hoop Stress is 5.5MPa |
No Failure |
|
80°C,1000h,Hoop Stress is 5.0MPa |
No Failure |
|
6.If you want to see more, i am so pleased to see you in our factory.
And if you have other question, you can contact me for free.
1.How to get free samples ?
A: Send your address ,your telphone number ,post code ,and express account number to our mail box .and told us which model of samples you need .
2.Who pay for the express cost ?
A: We can support you free samples each model 1-3 pcs ,and we do not pay for express cost .
3.What is your packing?
A: usually plastic bags,carton,can be packed as your require.
1 Genuine produces with excellent quality and competitive price.
2 Cooperating with the customers all over the world and knowing the markets very well.
3 After- Services will be highly-satisfied. Any problems and feedbacks will be answered in a short of time.
