Help CenterMost Competitive Price!! Three Layer Co-extrusion PET Film/Polyester Film/co-extrusion PET Film
Related Products
-
Transparent /Black Lldpe Stretch Film Jumbol Roll/lldpe Stretch Wrapping Film/black Lldpe Stretch FilmUS$ 1,000 - 1,600MOQ: 5 Tons -
Popular Hot Sale!! Food Grade PVC Twist Film for Candy Packing/PVC Film/PVC Candy Package FilmUS$ 1,000 - 1,700MOQ: 5 Tons
-
Manufacturer!! Bopp Film Transparent/BOPP Corona Film/bopp Thermal Lamination FilmUS$ 1,000 - 1,600MOQ: 5 Tons
-
New Discount !!LDPE Agricultural Film/LDPE Agricultural Film for Greenhouse Film/greenhouse FilmUS$ 980 - 1,600MOQ: 5 Tons
-
Polyurethane Film/TPU FILM ( Including Only C.H.O.N )/transparent TPU FilmUS$ 1,000 - 2,500MOQ: 5 Tons
Specification
Spec | ||||||||
Thickness |
Length |
Width |
Core size |
|||||
10~50 µm |
|
325mm~2500mm |
3”, 6” |
|||||
*) Other specifications on request. The typical lengths of reel roll equal to 12 µm film roll lengths are 6000m, 12000m, 18000m,24000m and 36000m. | ||||||||
|
The film is processed by three layer co-extrusion. Low heat shrinkage. High combination with multiple resin. High tensile strength. One side corona treatment is available. Stable quality. | ||||||||
Physical Property | ||||||||
Properties |
Unit |
Typical Value |
Scope |
Method |
||||
Thickness |
TD |
µm |
tolerance±4% |
12±0.2 |
DIN 53370 |
|||
Tensile Strength |
MD |
N/mm2 |
>200 |
100~235 |
ASTM D882 |
|||
TD |
N/mm2 |
>220 |
245~280 |
ASTM D882 |
||||
Elongation |
MD |
% |
>100 |
130~160 |
ASTM D882 |
|||
TD |
% |
>100 |
105~125 |
ASTM D882 |
||||
E Module |
MD |
N/mm2 |
>4000 |
4000~4300 |
ASTM D882 |
|||
TD |
N/mm2 |
>4200 |
4400~4800 |
ASTM D882 |
||||
Haze |
TD |
% |
2.5~3.0 |
2.5~3.0 |
ASTM D1003 |
|||
Heat Shrinkage |
MD |
% |
<1.55 |
1.3~1.5 |
BMSTT11 |
|||
TD |
% |
<-0.1 |
-0.1~-0.25 |
BMSTT11 |
||||
Wetting tension |
TD |
mN/m |
>54 |
58 |
ASTM D2578 |
|||
|
Remark: MD is machine direction, TD is transverse direction. The values above can not be understood as guaranteed values. They are only the basic test values for your reference. If required can be adjusted according to your requirements.l Listed are the average test values token from 6.2m,6.7m and 8.7m width jumbo roll | ||||||||
