Specifications
1.1x dry contact output2.6 LED indicator lights
3.RS485 communication interface
Wholesale Room VOC detector
¨ Features
u Wall mounting, real time detect indoor air quality
u With excellent mix gas sensor inside. 5~7 years lifetime.
u High sensitive to contaminative gases and various kinds of odorous gases within the room (smoke, CO, alcohol, human odor, material odor).
u Special temperature and humidity compensation makes the VOC measurements consistent in different environment
u One 0~10VDC or 4~20mA linear output for the IAQ measurement.
u Easy to select the analog output by jumpers.
u Optional Modbus RS-485 communication interface 15KV antistatic protection, independent address setting.
¨ Application
u Detect Indoor Air Quality
u Can be used in houses, offices, theaters, shops, restaurants, train stations and many other places
u Ventilation control systems
NOTE:F2000TSM-VOC-S100 cannot be used as a safety detector, for example, gas alert detector.
¨ Specifications
Gas detected | VOCs ( toluene emitted from wood finishing and construction products); Cigarette smoke( hydrogen, carbon monoxide); ammonia and H2S, alcohol, natural gas and smell by people’s body. |
Sensing element | Semiconductor mix gas sensor |
VOC measuring range | 0~30ppm |
Power Supply | 24VAC/VDC±10% |
Consumption | 2.5 W |
Sensor query frequency | Every 1s |
Warm up time | 48 hours (first time) 1 hour(operational) |
Analog output | 0~10VDC linear output (default) 4~20mA selectable by jumpers or in the order |
Output resolution | 10Bit |
Modbus Communication rate | RS485, 19200bps(default), can be adjusted via Modbus protocol. 15KV antistatic protection, independent base address, 64 max network nodes |
Operation temperature | 0~50°C (32~122°F) |
Operation humidity | 0~95%RH,non condensing |
Storage conditions | -40~70°C (-40~158°F) |
Weight | 190g |
Dimensions | 100mm×80mm×28mm |
Installation standard | 65mm×65mm or 2”×4”wire box |
Housing and IP class | PC/ABS Plastic fireproof material , IP30 class |
Quality standard | ISO 9001 |
CE approval | EMC 60730-1: 2000 +A1:2004 + A2:2008 Directive 2004/108/EC Electromagnetic Compatibility |
¨ Models
ITEM | MODEL | DESCRIPTION |
IAQ Transmitter (wall mounting)
Power supply: 24VAC/VDC | F2000TSM-VOC-S110-V | IAQ sensor/transmitter with 0~10VDC linear output. |
F2000TSM-VOC-S110-A | IAQ sensor/transmitter with 4~20mA linear output. | |
F2000TSM-VOC-S110-V/A | IAQ sensor/transmitter with 0~10VDC linear output. (Can be selected 4~20mA by jumpers) | |
F2000TSM-VOC-S110C | IAQ sensor/transmitter with 0~10VDC linear output. (Can be selected 4~20mA by jumpers) Modbus RS485 interface |
1) Wall mounting, VOC detector is used to real time detect room VOC level
2) With Japanese famous semiconductor mix gas sensor, 5~7 years lifetime.
3) The sensor is sensitive to VOC such as various kinds of odorous gases and combustion gas in the room (smoke, CO, alcohol, human odor, material odor).
4) With 6 LED indicator lights to indicate different IAQ levels.
5) One on/off output optional with four IAQ ranges selectable to control the relay output. A touch button on the cover to switch Fan On/Fan Off/Auto Fan
6) 24VAC/VDC power supply or 230VAC power supply with a power adaptor
