Home > Products > CO2 Controller for Greenhouse > co2 hydroponic
co2 hydroponic
- 2000 Piece / Pieces per Month
- Beijing
- High quality Portable Industrial Automatic Humidistat
- Weatherproof plant grow bags for vegetable and flower
- High Quality Removable outdoor plant grow bag
- Weatherproof plant grow bags for vegetable and flower
- 7 Gallon Black Breathable Felt Fabric Grow Bags
- Fabric Grow Bag Smart Pots With Handles For Potato
Product Details
Size: | Large | Model Number: | TKG-CO2-1010D-PP | Place of Origin: | Beijing, China |
Brand Name: | Tongdy |
Product Description
co2 hydroponic
co2 hydroponic Features:
Special used to real-time detect CO2level in air ducts.
NDIR infrared CO2 sensor inside with Self-Calibration and up to
15 years lifetime
High accuracy humidity and temperature detection &display optional
With LCD or without LCD selectable
Providing one dry contact output with presetting the setpoint
Modbus RS485 communication interface optional
Wireless of ZigBee protocol optional
Smart structure with easier wire connection through the external pipe
Provide four types: wall mounted, duct mounted, split and plug & play
For plug & play type, special design a photosensor inside to detect
day/night and change the working mode of the CO2 generator
For duct probe type, special the 180° rotatable fastness position of the
probe can be used in two directions of air flow.
Replaceable filter in the probe and extendable probe length
Design the convenient and easier buttons for operation
CE-Approval
Specifications
CO2 Sensor | Non-Dispersive Infrared Detector (NDIR) | |
Measurement Range | 0~2,000ppm (default) 0~5,000ppm (preset) | |
Accuracy | ±30ppm + 3% of reading @22°C(72°F) | |
Stability | <2% of full scale over the life of the sensor | |
Calibration | Self-calibration system | |
Response Time | <5 minutes for 90% step change at low duct speed | |
Non-linearity | <1% of full scale @22°C(72°F) | |
Duct Air Velocity | 0~450m/min | |
Pressure Dependence | 0.135% of reading per mm Hg | |
Warm up time | 2 hours (first time) 2 minutes (operation) | |
Split CO2 sensor | 2 meter cable connection between the senor and the controller | |
Temperature & Humidity Detection&Display (optional) | Temperature | Relative Humidity |
Sensing element: | Band-gap-senor | Capacitive humidity sensor |
Measuring range | -20°C~60°C | 0 -100%RH |
Accuracy | ±0.5°C (20~40°C) | ±4.5%RH (25°C, 15%-85%RH) |
Display resolution | 0.1°C | 0.1%RH |
Stability | ±0.1°Cper year | ±1%RH per year |
General Data |
| |
Power supply | 24VAC/24VDC or 100VAC~240VAC | |
Consumption | 1.8 W max. ; 1.0 W avg. | |
LCD display | Display CO2 measurement or CO2 + temperature& humidity measurements | |
Dry contact output (optional) | 1xdry contact output for CO2 Max. 5A (100~240VAC/30VDC)rated switch contact | |
Plug& play type | Just for 100VAC~240VAC power supply with European or American power plug and power connector to the CO2 generator | |
Modbus RS485 Interface (optional) | 19200bps, 15KV antistatic protection. | |
Wireless module (optional) | ZigBee 2.4G short distance wireless communication | |
Operation conditions | 0°C~50°C(32~122°F); 0~99%RH, non condensing | |
Storage conditions | 0~60°C(32~140°F)/ 0~80%RH | |
IP class | IP30 | |
Standard Approval | CE-Approval |
Typical Applications
In office and residence areas to detect CO2 level
Ventilation control
In BAS to detect the CO2 and the data transmittance
For greenhouse and plant bin
For CO2 laboratory.
