Vehicle Carbon Monoxide Detection Kitchen Rooms and Restaurants

Tongdy Sensing Technology Corporation (Beijing)
Vehicle Carbon Monoxide Detection Kitchen Rooms and Restaurants thumbnail-1
Vehicle Carbon Monoxide Detection Kitchen Rooms and Restaurants photo-1
US$ 100 - 100 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Tongdy
Model Number:
G09-CO
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
EXW Beijing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name Tongdy
Model Number G09-CO
Usage Gas Sensor
Theory Other, electrichemical CO sensor
Output Analog Sensor

Vehicle carbon monoxide detection Kitchen rooms and restaurants



Home Useage Carbon Monoxide Monitor Kitchen Places CO Alarmer



Vehicle carbon monoxide detection Kitchen rooms and restaurantsVehicle carbon monoxide detection Kitchen rooms and restaurants





n   Features



   1. Designed for real time measuring ambiance carbon monoxide level, temperature and relative humidity.

   2. Particular LCD display with three color backlit (Green/Yellow/Red)

   3. Electrochemical CO sensor with up to 5 years life time

  5. Two stages alarm prese Two alarm ways: buzzer alarm and backlight colours changeover

<![i     6.Provide up to 2 relay dry ontact outputs to control a fan and an alarm

<      7. Provide 1X analog linear output (0~10VDC/4~20mA selectable) for the measurement

        8 Modbus RS–485 communication interface, 15 KV antistatic protection, individual IP address





n  Application



G09-CO series is used to detect and monitoring indoor carbon monoxide and temperature, as well as optional humidity. With one analog output,

the carbon monoxide measurement can be transmitted to a DDC/PLC or other system. Two dry contact outputs can control a fan and an alarm according with the preset setpoints.

With the Modbus RS-485 communication interface, it can be connected with a DDC/PLC or other system.



1.Residential and commercial carbon monoxide detection

2.Ventilation control for indoor parking lots

3.Vehicle carbon monoxide detection

4.Kitchen rooms and restaurants

5. Freezing machine rooms and other places where air quality is easy to worsen





n  Models Guide



G09–CO–ABC1-Y
A-LCD             ( 2: with LCD, no humidity option, 3: with LCD and with humidity)

B-analog output      (0: no analog output, 1: 0~10VDC output, 2: 4~20mA output)

C-dry contact output  (0: no dry contact output, 1: 1Xdry contact output, 2: 2Xdry contact outputs)

1-Modbus RS485

 Y-CO range         (001: 0~100ppm,  002:0~200ppm,  005:0~500ppm,  010: 0~1000ppm)



 Example: G09-CO-2021-005 indicates the CO detector with 2X on/off dry contact outputs and a Modbus RS485 interface, and the CO range: 0-500ppm.

G09-CO-3101-010 indicates the CO detector with 1X 0~10VDC output and a Modbus RS485 interface, LCD display. Humidity option.

CO range: 0-1000ppm.



FAQ



 Vehicle carbon monoxide detection Kitchen rooms and restaurants

Shipping and Packing



 Inner Package: Standard Product Cartons

Outter Package; Standard TNT<DHL, and other Satandard Carton







 Vehicle carbon monoxide detection Kitchen rooms and restaurants
