Can be used communications remote control high voltage ups for home appliances
- 100 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
- Stackable Rack Energy Storage System Home energy storage system 5kWh 10kWh 15kWh and 20kWh
- Schneider Electric UPS
- Solar Generator With 5000W Inverter Portable Pull Rod LiFePO4 Battery Power Station
- 3000W Power bank EPS AC220V portable energy storage home power supply
- 5KW Outdoor Mobile Portable power station 220V Type-C DC12V DC5V Output UPS
- 500W portable UPS LFP Battery Solar Generator Backup Power Station
Product Details
Place of Origin: | Guangdong, China | Brand Name: | AY | Model Number: | AY9830C |
Phase: | Three Phase | Protection: | Overvoltage | Weight: | 250kg |
Output Voltage: | 380/400VAC/415VAC | Type: | On-line | Application: | Other, computer; date center; network administration center and other equipme |
Product Description
Can be used communications remote control high voltage ups for home appliances
Competitive Advantage:
- High speed MCU control, it can do parameter setting, running progress management, self-test, self-detective, and so on. Also can detect all the independent circuits, and do faults protection.
- With high speed switch, high voltage, large current, makes efficiency higher, driver circuit smaller, and improve the system efficiency and reliability.
- 3phase independent modulation, full bridge Inverter designed, it can be 100% unbalance load in 3phase.
- Rectifier/Charger Integrated design, charging capacity is configured according with battery, user can set up parameters with operation platform, and charging current can be configured by software automatically, also can configure battery self-test, charging/discharging interval time, and keep battery long life.
- RS232contact can be used for communications and remote control.
- Large LCD display, it can show UPS running status, running progress, UPS parameter data, fault events, etc.
- With various system protection. As over voltage, low voltage, over current, over load, short circuit, etc can be detected, and supply reliable protection.
Photo showing
MODEL | AY9830C | |
Capacity | 80KVA | |
INPUT | ||
Rated Voltage | 380/400VAC/415VAC | |
Rated Frequency | 50/60Hz Auto Sensing | |
Frequency Range | 40-70Hz | |
Power Factor | ≥0.95 | |
OUTPUT | ||
Voltage | 220V/230V/240VAC | |
Voltage Regulation | ±1% | |
Frequency | Synchronized with utility on AC mode;50/60±0.1Hz on battery mode | |
Waveform | Pure sine wave | |
Transfer Time | AC mode to battery mode :0ms Inverter model to bypass mode:0ms | |
SYSTEM | ||
Efficiency | ≥85% | |
Protection | Output short circuit, overload, output over/low voltage, battery low, over temperature | |
ENVIRONMENT | ||
Humidity | 0~95% RH & 0~40℃(non-condensing) | |
Noise Level | ≤55dB | ≤60dB |
AY9830C Introduction
AY9830C 3phase large power UPS (80KV), offer advanced DSP control, high speed 16 bits digital IC, DDC control technology, also use advanced high power IGBT and SCR, it is a digital, Information, Networking, Online Intelligent Pure Sine-wave Uninterruptible Power Supply, which is based on reliable, advanced, high efficiency digital/analog hybrid technology. AGP003M can supply strong power guard for you.
AY9830C series UPS can be widely used in the filed of finance, telecommunication, revenue, traffic, insurance, government, corporation etc.
Shenzhen An Ying Technology Co.,Ltd was established in 2009.Our company has strong science and technology strength.Otherwise ,there are many high quality researching talents who own the master's and bachelor's degree.We have established the LED department and machine room monitoring departmen under our common efforts.We specialize in researching ,producing and processing LED lighting, leak detector,machine room monitoring device.The head office is located in Shenzhen.There is complete and scientific quality management system in Shenzhen An Ying Technoloey Co.,Ltd . The honesty, the strength and the high quality of the products has been recommended by the industy and the customers in the world. Your presence and guidance ,or business negotiation are warmly welcome.
