HDPE carbon corrugated pipe for cable protection
Corrugated pipe , HDPE carbon corrugated pipe, HDPE carbon corrugated pipe for fiber optic cable
Specifications
HDPE carbon corrugated pipe for cable protection
Corrugated pipe , HDPE carbon corrugated pipe, HDPE carbon corrugated pipe for fiber optic cable
high quality hdpe carbon corrugated pipe for conduit
1,Corrosion resistance.,Good insulation
2,Easy to thread.
carbon corrugated tube advantages:
HDPE carbon corrugated pipe for cable protection
Corrugated pipe , HDPE carbon corrugated pipe, HDPE carbon corrugated pipe for fiber optic cable
|
1. Good flexibility: The carbon corrugated pipe with special spiral shape is provided with good performance. The flexibility allows it to be curved under, over & around obstacles as well as directional changes. The carbon corrugated pipe is flexible and could be easy installed in a variety of trenchless ways. |
|
2. Enough length per each: The carbon corrugated pipe with optional length of each roll. Deducting connector used and easy installation and convenient maintenance. |
|
3. Light weight: The carbon corrugated pipe is light weight lower than concrete pipe, iron pipe, steel pipe and PVC pipe. The electrical tube is easy to carry and move with low labor strength. |
|
4. High Intensity: The carbon corrugated pipe with special spiral structure, high compression strength, will not be deformed with high pressure underground. |
|
5. Corrosion resistance: The carbon corrugated pipe with high ability to resist to acid, alkali, salt and other various types of chemicals. It will be used long time. |
|
6. Safety: The corrugated carbon pipe with high anti-loading ability, high reel ability and high intensity. It will not be split and keep safety against subsidence of ground even if earthquake. |
|
7. Easy to draw cables: The electrical tube with smooth inner wall surface which has low friction coefficient. There is one piece of galvanized wire in the duct to help drawing cables easily. |
|
8. Trust worthy: The carbon corrugated pipe has been tested and examined strictly by institute of supervision & inspection. It meets the requirement of technical standards and could be trusted as upgrading of traditional pipes. |
|
9. Lower construction and maintenance costs: The carbon corrugated pipe could be installed quickly and shorten constructions period and reducing installation costs with significant social and economic benefits. |
TDS
HDPE carbon corrugated pipe for cable protection
Corrugated pipe , HDPE carbon corrugated pipe, HDPE carbon corrugated pipe for fiber optic cable
Model ID OD peak at potential length (m)
Φ50 49.5 ± 2.5 67 ± 1.0 17 ± 1.0 200
Φ65 65 ± 2.0 84.5 ± 2.5 21 ± 1.0 200
Φ80 80 ± 3.0 105 ± 3.0 25 ± 1.0 100
Φ100 100 ± 4.0 130 ± 4.0 30 ± 1.0 100
Φ125 125 ± 4.0 160 ± 4.0 38 ± 1.0 100
Φ150 150 ± 4.0 185 ± 4.0 45 ± 1.0 50
Φ175 175 ± 4.0 230 ± 4.0 55 ± 1.0 50
Φ200 200 ± 4.0 260 ± 4.0 60 ± 1.5 40
Carbon corrugated tube Specifications
HDPE carbon corrugated pipe for cable protection
Corrugated pipe , HDPE carbon corrugated pipe, HDPE carbon corrugated pipe for fiber optic cable
1, No uneven appearance inside and outside surfaces, no similar defects
2, The pressure within the experimental 30s load 750N (stress type), continuous 1min, diameter change rate of less than 25%
3, The impact test at 60 °C for 240h, and placed at 0 °C 2h, at 300mm height with 2.0Kg hammer (big stress type) shocks, without damage.
4, The insulation resistance, MΩ ≥ 100
5, Voltage resistance 15min no breakdown voltage 2000V
6, Pipe cold pipe at 90o to 180o performance range can bend, visually no obvious structural defects
7, Ring stiffness ≥ 18.0
1) With 10 years of professional experience in custom plastic industry.
2) Large production capacity: 1,000,000 meters /month. Short Lead time for containers production within 7-25 days.
3) Nearly 150 employees, Most of them have rich experience over 8 years , we have rich experience in manufacture and work with high efficiency.
4.)Strict quality control under SGS, ISO. and QS. Our QC department strictly carries on a precise process to ensure best quality.
5) Our competitive price will help your entry into new market and defeat your potential competitor.
6.)Professional sales and a customer service team. To ensure the best service, our team will solve your problems within 12 hours.
