Halogen Infrared Heating Lamp for Solar PV Industry,quartz Tube

Name: Halogen Infrared Heating Lamp for Solar PV Industry,quartz Tube
Brand: Quickly
SKU: 141796410
Availability: InStock

US$ 1 - 200 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Quickly

Color:

Other, transparent, Yellow, white coated

Hefei Quickly Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Quickly

Color Other, transparent, Yellow, white coated

Specification Other

Material Other, quartz, Quartz, high-calss imported quartz sand and heating filament

Certification Other, CE, CE, CE approved by EMC

Product PV

Technical Parameters

Voltage	100, 110, 120, 220, 230, 240 V
Wattage	300 -6000W
Dia	10,12,15,20,818,2311,33*15mm
Electricity saving rate	35%
Wavelength	1.0-1.4um
Response Time	1s
Electric heat transformation rate	>98%
Temperature(surface)	2200℃
Max heating length	6400/2400mm
Wire temperature	1800 ° - 2400 °C
Max power per unit area	200 kW /m2

IR Benefits and Features

Long life	More than 5000h
Instant heat	within 1 second reaction time
High power density	< 200w/cm
High control ability	neither ballast nor special circuits are necessary for basic usage
No air droughts	because of radiation
Clean	No byproducts, no pollution
Extensive assortment	voltage,wattage,length,base,cables and other specifications are available
High efficiency	more than 85% heat efficiency of full power.
Economical	More than 85% of consumed energy transmitted into infrared heat
Heat can be focused	Same optical properties as light,can be directed by reflectors
Safe	Quartz envelope, heat shock resistant
