Quartz Halogen Infrared Heater Lamp for Tunnel Oven

Name: Quartz Halogen Infrared Heater Lamp for Tunnel Oven
Brand: Quickly
SKU: 141796398
Availability: InStock

US$ 1 - 200 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Quickly

Color:

Other, transparent, Yellow, white coated

Hefei Quickly Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Quickly

Color Other, transparent, Yellow, white coated

Specification Other

Material Other, quartz, Quartz, high-calss imported quartz sand and heating filament

Certification Other, CE, CE, CE approved by EMC

Product Description

Photovoltaic Solar Application

Product		Short wave IR heat lamp	Medium wave IR heat amp
Wave length		0.75-1.0μm	2.4-2.7μm
Heating response time		1 second	1-4min
Voltage		110v/230v/380v/400v,customized available
Max. Length for twin tube		6000mm
Max. filament temp		2200°C	900°C
Watt density		35-200w/cm	10-30w/cm
Working expectation		5000hours	20000hours
Dia. of twin tube		23×11mm / 33×15mm
Wall thickness of tube		0.8mm,1.0mm,1.2mm,1.5mm,1.8mm
Dia. of single tube		Φ10mm, Φ11mm, Φ12mm, 15mm,18mm, 20mm
Max. length for single tube		1600mm(Φ12mm)	2000mm(Φ15mm)
Main material	filament	tungsten filament	Ni80Cr20 heating wire
	quartz glass	can resist high temperature, sudden hot and cold
Inner structure of quartz tube		Quartz envelope profile , vacuum processing with protective halogen gas inflation, which provide a safe working environment	Quartz envelope profile , Non-vacuum
Surface of quartz tube		1. White reflector/Gold reflector: High heat radiation rate 2. Transparent tube: Normal style 3. Ruby tube for shortwave
