transparent quartz halogen infrared heating lamp for sintering furnaces and spary daying,Ce certificate,5000 hours
USD $42 - $156
/ Meter
100 Meters(Min.Order)
- 10000 Piece / Pieces per Month
- shanghai
- T/T Credit Card
You May Like
-
Heater Core Heater Welding Gun Heater Element
-
Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
-
Preheating equipment for hardbandig welding
-
Heater Core Heater Welding Gun Heater Element
-
DL-3 model electric air heater with upper outlet and lower inlet
-
DL-2 model electric air heater with Left-Right Circulation
Product Details
| Condition: | New | Type: | Other, Infrared Heater, transparent short-wave Infrared heating lamp | Power Source: | Other |
| Place of Origin: | Anhui, China | Brand Name: | KKL | Dimension(L*W*H): | 23mm*1.5mm*15 |
| Weight: | 0.5KG | Voltage: | 110V,220V,380V, 110V, 220V, 240V, 380V, customized. | Power(W): | 0.3-6KW |
| Certification: | CE, CE, CE approved by EMC | Warranty: | 5000h, 5,000 hours | After-sales Service Provided: | No overseas service provided |
Product Description
Infrared lamp
Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation
(light)-- infrared light from material in the form of molecular (atomic) resonance absorption,
so as to achieve the purpose of heating. It can be applied in many fields such as the
heating process of industry coating, plastic forming, automotive industry, glass making,
spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint
on furniture, printed circuit, and so forth.
Specifications:
- · Infrared quartz tube
- Lifespan: 5000 hours
- Certification: CE
- Suitable for new type quartz tube heaters
- Voltages: 110, 220 or 380V or other voltage grades needed by users
- Power: 0.3 to 6kW
- Length: 300 to 3000mm
- Outer diameter: 23-33mm
- Surface temperature of heater divides into three grades:
- o Low temperature: 400 to 600℃
- o Mid temperature: 600 to 800℃
- o High temperature: 800 to 1000℃
- Wavelength:1.0-1.4um
- Reaction time:1S
Advantages:
- Process, design and products can be customized
- · 5000 hours lifespan
- · CE certification
- · Small order accepted
- · Science,energy saving,safety and environmental protection
- · Single-ended wire
- · Very short time of heating and cooling
- · Reasonable price
Detailed Images
Application
Contact Us
- Hefei Quickly Electric Co., Ltd.
- Contact nameArthur Cao
- Phone86-551-65208999
- Addressxinbengbu road Hefei,Anhui
