Shortwave Infrared Lamp,infrared Radiation Heating Element for Curing Oven

Name: Shortwave Infrared Lamp,infrared Radiation Heating Element for Curing Oven
Brand: Quickly
SKU: 141795832
Availability: InStock

US$ 1 - 200 MOQ: 300 Pieces

Key Specifications

Condition:

New

Type:

Other, Infrared Heater, shortwave infrared lamp,infrared radiation heating element

Power Source:

Electric

Hefei Quickly Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Infrared Heater, shortwave infrared lamp,infrared radiation heating element

Power Source Electric

Place of Origin Anhui, China

Brand Name Quickly

Voltage 110-240V / 50-60Hz, 110V, 220V, 240V, 380V, customized.

Power(W) 1w-10000w

Certification CE Certification, CE approved by EMC

Warranty 5000-2000hours

After-sales Service Provided No overseas service provided

Product Description

Technical Parameters

Voltage	100, 110, 120, 220, 230, 240 V
Wattage	300 -6000W
Dia	10,12,15,20,818,2311,33*15mm
Electricity saving rate	35%
Wavelength	1.0-1.4um
Response Time	1s
Electric heat transformation rate	>98%
Temperature(surface)	2200℃
Max heating length	6400/2400mm
Wire temperature	1800 ° - 2400 °C
Max power per unit area	200 kW /m2

IR Benefits and Features

Long life	More than 5000h
Instant heat	within 1 second reaction time
High power density	< 200w/cm
High control ability	neither ballast nor special circuits are necessary for basic usage
No air droughts	because of radiation
Clean	No byproducts, no pollution
Extensive assortment	voltage,wattage,length,base,cables and other specifications are available
High efficiency	more than 85% heat efficiency of full power.
Economical	More than 85% of consumed energy transmitted into infrared heat
Heat can be focused	Same optical properties as light,can be directed by reflectors
Safe	Quartz envelope, heat shock resistant

Compare

Infrared Heating VS Traditional Heating
Name	heating way	heating medium	quality	Power conversion efficiency	source	environment	heating section
Infrared heaitng	infrared radiation	no	good	95%	electric	green, no byproducts, no pollution	from inside to outside
Traditonal heating	air convection	air	surface with wrinkle and bubble	less 40%	Combustible gases, Flammable liquids, Coal	byprodcut, pollution	surface
Conclusion	ueing shorter time to heat and cool, reducing cost from long term, improving product quality, high efficiency,environmental protection
