Home > Products > Special Transformer > special bridge rectifier transformer
special bridge rectifier transformer
- 500 Set / Sets per Month
- tianjian shanghai ningbo qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Hebei, China | Brand Name: | Tianwei | Model Number: | ZBS ZZS |
Usage: | Power | Phase: | Single | Coil Structure: | Toroidal |
Coil Number: | Autotransformer |
Product Description
special bridge rectifier transformer
Features of JCK Series input ac reactor
1.Light weight;
2.Small in size;
3.Easy to debug;
4.Strong over-load capacity;
5.Good performance of short circuit
1. Low loss, low noise
2. Safe and reliable service
3. Easy erection and maintenance
4. Careful fabrication
Type | Current (A) | Inductance (mH) | Weight (kg) | Overall Dimension (mm) | ||
Length | Width | High | ||||
JCK-20/1.4 | 20 | 1.4 | 6 | 200 | 120 | 160 |
JCK-25/0.98 | 25 | 0.89 | 7 | 200 | 120 | 190 |
JCK-35/0.8 | 35 | 0.8 | 8 | 200 | 120 | 190 |
JCK-40/0.7 | 40 | 0.7 | 12 | 210 | 120 | 200 |
JCK-50/0.56 | 50 | 0.56 | 15 | 210 | 120 | 210 |
JCK-80/035 | 80 | 0.35 | 25 | 280 | 130 | 310 |
JCK-100/0.28 | 100 | 0.28 | 35 | 350 | 160 | 390 |
JCK-120/0.23 | 120 | 0.23 | 40 | 370 | 160 | 450 |
JCK140/0.2 | 140 | 0.2 | 45 | 390 | 160 | 420 |
JCK-160/0.15 | 160 | 0.15 | 50 | 395 | 175 | 350 |
JCK-220/0.13 | 220 | 0.13 | 55 | 340 | 160 | 480 |
JCK-240/0.12 | 240 | 0.12 | 60 | 420 | 190 | 450 |
JCK-270/0.104 | 270 | 0.140 | 70 | 430 | 180 | 500 |
JCK-300/0.093 | 300 | 0.093 | 75 | 380 | 195 | 480 |
JCK-350/0.080 | 350 | 0.080 | 80 | 430 | 185 | 490 |
JCK-400/0.070 | 400 | 0.070 | 85 | 490 | 230 | 550 |
JCK-450/0.062 | 450 | 0.062 | 95 | 460 | 220 | 600 |
JCK-510/0.055 | 510 | 0.055 | 105 | 480 | 300 | 550 |
JCK-560/0.050 | 560 | 0.050 | 110 | 500 | 300 | 550 |
JCK-600/0.047 | 600 | 0.047 | 120 | 520 | 300 | 550 |
JCK-630/0.045 | 630 | 0.045 | 125 | 530 | 300 | 300 |
JCK-700/0.040 | 700 | 0.040 | 130 | 530 | 300 | 610 |
JCK-800/0.035 | 800 | 0.035 | 135 | 540 | 300 | 680 |
1 .Customized design depends on your requirement. OEM is welcomed.
2 .Reply your inquiry in half of hour,24 hours on line.
3.Special discount and protection of sales area provided to our distributor.
4.Warranty:1year.1.Do you offer the samples of transformer?
Yes,we can provide sample with charge.
2. What is Amorphous Alloy?
An amorphous metal (also known as metallic glass or glassy metal) is a solid metallic material, usually an alloy, with a disordered atomic-scale structure. Most metals are crystalline in their solid state, which means they have a highly ordered arrangement of atoms.Amorphous metals are non-crystalline, and have a glass-like structure. But unlike common glasses, such as window glass, which are typically electrical insulators, amorphous metals have good electrical conductivity.
3.Advantages of Amorohous alloy
The amorphous is more superior to traditional silicon steel sheet in magnetic permeability, excitation current and iron losses, especially in iron losses, only 1/3 to 1/5 when compared with silicon steel sheet.
1. Small space occupy and easy installation. 2. Low loss 3. Better efficiency in power using 4. Long service time 5. Wide application range.
4.Do you take special orders ?
Yes , We accept customized products.
