Greenhouse galvanized steel pipe constraction picture look
Greenhouse galvanized steel pipe constraction picture look
Greenhouse galvanized steel pipe picture look
Galvanized steel pipe specification
specification |
Chemical composition(%) |
||||||||
No. |
Weight(kg/m) |
Elongation |
Tensile strength |
Yield Strength |
C |
Si |
Mn |
P |
S |
50*50*2.0 |
15.89 |
22% |
428N/mm2 |
225 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
32*1.5*7.95 |
9.184 |
23% |
428 N/mm2 |
217 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
25*1.5*4.47 |
3.27 |
24% |
427 N/mm2 |
216 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
32*1.5*4.47 |
11.60 |
27% |
420 N/mm2 |
218 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
50*50*1.5 |
14.775 |
20% |
428 N/mm2 |
229 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
25*25*1.5 |
14.25 |
25% |
422 N/mm2 |
225 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
32*1.5*4.07 |
13.98 |
26% |
419 N/mm2 |
221 N/mm2 |
0.07 |
0.1 |
0.35 |
0.017 |
0.031 |
.
The film greenhouse technicial date
Specification |
Index |
Product type |
UV Film |
Nominal Thickness |
150, 180, 200 micron |
Light Transmission (%) |
>88 % |
Temperature |
-15 ℃—60 ℃ |
Tensile Strength |
≥30MPa |
Tear Resistance |
≥580%
|
The film greenhouse specs
Specification |
Index |
Cover |
inflatable film |
Style |
Dome |
Framework |
Hot dipped galvanized steel |
Wind load(KN/m2) |
0.60 |
Snow load(KN/m2) |
0.50 |
Constant load plus(Kg/m2) |
15 |
Impact strength |
850J/m |
Light Transmission |
>88% |
Heat Conductivity |
0.2W/(m.K) |
Range of temperature |
-15°C ~60°C |
We can provide the parameters above depends on the local climate.
Size |
Index |
Width(m) |
9.6m |
Length(m) |
40m |
Height(m) |
6m |
And the size can be manufactured as your requests.
sun shade net hydroponic system
1.shade rate:30-90% for different kinds of planting
lor:any color is available 2.system supervision
Ventilation system cooling system
1.good at natural ventilation 1. kinds of frame sizes for choice
2. system supervision 2. high absorbability, high water resistant
>View more " href="http://xlonghouse.en.china.cn/productgrouplist-803060884/Complementary_System.html">>>View more
step 1: engineer the greenhouse drawing and plan
step 2: the greenhouse cover material is packed in woven bag
step 3: provide English greenhouse introduction
step 4: checking the waterproof index to fit for suitable and practical package
step 5: communitcate with the logistic to check the suitable details
step 6:control each line of shippment .
