Electrical roll up motor
Rated power | Voltage | Output speed | Output torque | Rolling length | Weight | Unit | Rated power |
40W | DC24V | 3.6rmp | 45N.m | ≤65m | 2.0kg | Set | 40W |
50W | DC24V | 3.6rmp | 55N.m | ≤75m | 2.5kg | Set | 50W |
60W | DC24V | 3.6rmp | 60N.m | ≤85m | 3.2kg | Set | 60W |
100W | DC24V | 3.6rmp | 100N.m | ≤100m | 3.4kg | Set | 100W |
100W | DC24V | 3.6rmp | 100N.m | ≤100m | 3.5kg | Set | 100W |
180W | DC24V | 3.6rmp | 180N.m | ≤120m | 5.5kg | Set | 180W |
Electrical roll up motor feature:
1.support big power;
2. double limit protection;
3. limited positioning accuracy, higher self-locking performance;
4. increasing anti-condensation system design to ensure the safety of the circuit board;
5. the output shaft to strengthen the process;
6. three-year warranty;
Manually roll up motor (section)
Model | Output torque | Roll-rod length | Roll-height | Ratio | Application | Unit |
XL101 | 20N.m | ≤50m | 1.5m | 1:1 | Section roll up | Set |
XL102 | 30N.m | ≤90m | 1.5m | 4:1 | Section roll up | Set |
Manually roll up motor feature:
1.whole new generation of manual roll film device;
2.light weight, large torque;
3. strong, durable;
4. 3-year warranty;
Manually roll up motor (Top)
Model | Roll-rod length | Roll-height | Ratio | Application | Unit |
XL1102 | ≤100m | ≤5m | 1.5m | Top ventilation | Set |
Manually roll up motor feature:
1. easy to install, easy to operate, reliable self-locking performance;
2. the drive to increase a transmission gear, more stable performance;
3. the speed ratio, the output torque, light weight;
4. widely used, in addition to open the window film greenhouse, you can manually control a small area of the rack and pinion drive louvers;
1.Any kinds of roll up motor is available
2.The index of the roll up motor can be customized
3.Just feel free to tell us your greenhouse required,we will supply u a suitable equipment.
(Click here to contact)
No.1Our factory
No2.Focus on engineering design before and after service
No3. Focus on commercial greenhouse research and development
No4. Focus on upgrading greenhouse equipment
