Agriculture Greenhouse Roll up Motor

MY XL Greenhouse Tech And Dev Co., Ltd. Gold Verified Supplier
5Yrs
Agriculture Greenhouse Roll up Motor thumbnail-1
Agriculture Greenhouse Roll up Motor thumbnail-2
Agriculture Greenhouse Roll up Motor photo-1
Agriculture Greenhouse Roll up Motor photo-2
US$ 1 - 40 MOQ: 1 Piece
Key Specifications
Get Latest Price
Size:
Small
Type:
Other, greenhouse equipment
Cover Material:
Other, plastic/metal/steel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai beijing tianjin shenzhen guangdong chengdu chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Size Small
Type Other, greenhouse equipment
Cover Material Other, plastic/metal/steel
Model Number XL-2016
Place of Origin Sichuan, China
Brand Name XL
Material Other, steel & plastic

agriculture greenhouse roll up motor

                                             Electrical roll up motoragriculture greenhouse roll up motor



Rated power

Voltage

Output speed

Output torque

Rolling length

Weight

Unit

Rated power

40W

DC24V

3.6rmp

45N.m

≤65m

2.0kg

Set

40W

50W

DC24V

3.6rmp

55N.m

≤75m

2.5kg

Set

50W

60W

DC24V

3.6rmp

60N.m

≤85m

3.2kg

Set

60W

100W

DC24V

3.6rmp

100N.m

≤100m

3.4kg

Set

100W

100W

DC24V

3.6rmp

100N.m

≤100m

3.5kg

Set

100W

180W

DC24V

3.6rmp

180N.m

≤120m

5.5kg

Set

180W

Electrical roll up motor feature:

1.support big power;

2. double limit protection;

3. limited positioning accuracy, higher self-locking performance;

4. increasing anti-condensation system design to ensure the safety of the circuit board;

5. the output shaft to strengthen the process;

6. three-year warranty;

 agriculture greenhouse roll up motor

                                 Manually roll up motor (section)



Model

Output torque

roll-rod length

Roll-height

Ratio

Application

Unit

XL101

20N.m

≤50m

1.5m

1:1

Section roll up

Set

XL102

30N.m

≤90m

1.5m

4:1

Section roll up

Set

Manually roll up motor feature:

1.whole new generation of manual roll film device;

2.light weight, large torque;

3. strong, durable;

4. 3-year warranty;agriculture greenhouse roll up motor

                                      Manually roll up motor (Top)



Model

Roll-rod length

Roll-height

Ratio

Application

Unit

XL1102

≤100m

≤5m

1.5m

Top ventilation

Set



Manually roll up motor feature:

1. easy to install, easy to operate, reliable self-locking performance;

2. the drive to increase a transmission gear, more stable performance;

3. the speed ratio, the output torque, light weight;

4. widely used, in addition to open the window film greenhouse, you can manually control a small area of the rack and pinion drive louvers;





agriculture greenhouse roll up motor1.Any kinds of roll up motor is available

2.The index of the roll up motor can be customized

3.Just feel free to tell us your greenhouse required,we will supply u a suitable equipment.

(Click here to contact)





  agriculture greenhouse roll up motor



No.1Our factory

agriculture greenhouse roll up motor

No2.Focus on engineering design before and after service



No3. Focus on commercial greenhouse research and developmentagriculture greenhouse roll up motor

No4. Focus on upgrading greenhouse equipment

agriculture greenhouse roll up motor
