Help CenterFactory Direct Sale Core Veneer Composer Machine
Related Products
-
Automatic Plywood Making Machine Core Veneer Composer MachineUS$ 29,000 - 58,000MOQ: 1 Set -
Hydraulic Debarker Machine | Wood Log Debarking MachineUS$ 4,000 - 9,000MOQ: 1 Set
-
Hydraulic Log Debarker / Wood Log Debarker MachineUS$ 9,600 - 13,000MOQ: 1 Set
-
Linyi Wood Log Debarker&debarking MachineUS$ 4,000 - 90,000MOQ: 1 Set
-
Hydraulic Wood Debarker , Peeling Machine , Debarking MachineUS$ 9,600 - 13,000MOQ: 1 Set
| core veneer composer machine | |||||
| No. | Descriptions | Unit | WELL-VC1 | WELL-VC2 | WELL-VC3 |
| 1 | Knife length | mm | 1350 | 1350 | 1350 |
| 2 | Working veneer width | Max. mm | 1300 | 1300 | 1300 |
| 3 | After jointing size | mm | 1,300x2600mm | 1,300x2600mm | 1,300x2600mm |
| 4 | Veneer thickness | mm | 1.0-4.0mm | 1.0-4.0mm | 1.0-4.0mm |
| 5 | Feeding speed | Max. m/Min | 32(can be adjust) 6-7sheet (4*8ft) | 32(can be adjust) 6-7sheet (4*8ft) | 32(can be adjust) 6-7sheet (4*8ft) |
| 6 | Number of detectors | Point | 14 | 14 | 14 |
| 7 | Total power required | KW | 21 | 21 | 21 |
| 8 | In- feed conveyor (controlled by Servo Motor) | KW | 3 | 3 | 3 |
| 9 | Defect clipper | KW | 2.2 | 2.2 | 2.2 |
| 10 | Waste divider | Air- operated | 50×75 | 50×75 | 50×75 |
| 11 | Out feed conveyor (controlled by Servo Motor) | KW | 3 | 3 | 3 |
| 12 | Dimension clipper | KW | 1.5 | 1.5 | 1.5 |
| 13 | Cooling fan | KW | 0.5 | 0.5 | 0.5 |
| 14 | Water cooler | KW | 0.1 | 0.1 | 0.1 |
| 15 | Water circulation pump | KW | 0.1 | 0.1 | 0.1 |
| 16 | Table lifter for stacker | KW | 2.2 | 2.2 | 2.2 |
| 17 | Transferring conveyor | KW | 0.75 | 0.75 | 0.75 |
| 18 | Stacker belt conveyor | KW | 0.75/0.4 | 0.75/0.4 | 0.75/0.4 |
| 19 | Air consumption | Liter/Min | 60 | 60 | 60 |
,
I. Core Veneer Joint
1. After tenderized using PLC controller to cut the edge, joint the core and piece cutting.
2. After the core has been tenderized. The strong blower device can remove the dust one the core veneer.
3. The PLC controller enables cutting more precise, it can available reduce the odd core. It helps
control, monitor and maintenance more convenient.
4. The back-feeding wheel device is synchronizing with feeding speed, to avoid overlap or gap of
the jointing core.
5. It is equipped with hot melt glue yarn for help jointing. Cooling water tank of glue yarn is circle well by the cooler. It gets the best joint.
II. Stacker
Composed veneer after cutting, clearing dust, received by stacker.
1. In front of stacker, there is a strong blower to clear dust and clip for after stacking the core can be send to glue spread process directly.
2. The mid pressing bar and the side stacking wheel rack can be moved free for easy adjustment
in the dimension easy to collection.
